GEAR SHIFT SHAFT / LEVER

FRAME FOR YAMAHA WR 450 F YAMAHA BLUE 2019

FENDER

(1) B3J-21101-00

FRONT FRAME COMP.

(2) B3J-21447-00

BRACKET, FOOTREST

(3) 17D-21448-00

BRACKET, FOOTREST

(4) 901491003300

SCREW

(4) 901491003300

SCREW

(5) BR9-21190-01

REAR FRAME COMP.

(6) 90105-08230

BOLT, FLANGE

(6) 90105-08230

BOLT, FLANGE

(7) 30X-22178-00

TENSIONER

(8) 4V4-22184-00

BUSH

(9) 90201-08045

WASHER, PLATE

(9) 90201-08045

WASHER, PLATE

(10) 90387-08041

COLLAR

(11) 95022-08040

BOLT, FLANGE

(12) BR9-22178-00

TENSIONER

(13) 93300-60839

BEARING

(14) 90387-086N4

COLLAR(1NL)

(15) 90105-08232

BOLT, FLANGE

(16) 956170810000

NUT, U

(17) 90201-08043

WASHER, PLATE

(18) B3J-21149-00

BRACKET, BATTERY BOX

(19) 90267-32146

RIVET, BLIND (2YK)

(20) 90105-10361

BOLT, FLANGE

(21) 957041050000

NUT, FLANGE(3BM)

(22) 90201-10045

WASHER, PLATE

(23) BR9-21417-00

BRACKET, FRONT LOWER 1

(23) BR9-21417-00

BRACKET, FRONT LOWER 1

(24) 2GB-21418-10

BRACKET, FRONT LOWER 2

(25) 90105-08143

BOLT, FLANGE

(25) 90105-08143

BOLT, FLANGE

(26) 90105-10176

BOLT, FLANGE

(27) 957041050000

NUT, FLANGE(3BM)

(28) 90201-10045

WASHER, PLATE

(29) 90105-10189

BOLT, FLANGE

(29) 90105-10189

BOLT, FLANGE

(30) BR9-21425-00

BRACKET, REAR UPPER 1

(31) BR9-21426-00

BRACKET, REAR UPPER 2

(32) 90105-08143

BOLT, FLANGE

(32) 90105-08143

BOLT, FLANGE

(33) B3J-2147A-00

GUARD, ENGINE 1

(34) 90119-06166

BOLT, WITH WASHER

(34) 90119-06166

BOLT, WITH WASHER

(35) 1SL-21163-01

HOLDER, CLUTCH CABLE

(36) 92012-06010

BOLT, BUTTON HEAD

(37) B7R-21163-00

HOLDER, CLUTCH CABLE

(38) 92012-06010

BOLT, BUTTON HEAD

(39) 90464-31002

CLAMP

(40) BR92171X0200

COVER, SIDE 6

(41) 90269-06081

RIVET

(42) BR9-24181-00

DAMPER, LOCATING 1

(43) BR9-24182-00

DAMPER, LOCATING 2

(43) BR9-24182-00

DAMPER, LOCATING 2

(44) BR9-24183-00

DAMPER, LOCATING 3

(44) BR9-24183-00

DAMPER, LOCATING 3

(45) 5ET-28166-10

WRENCH, HEXAGON

(46) 18P-2467E-00

CAP

(47) 18P2464V0100

CASE, CAP

(48) B7R-28199-40

MANUAL,OWNER'S

(48) B7R-28199-70

MANUAL,OWNER'S

	Part number	Description	Qty
# 1	B3J-21101-00 B3J2110100 B3J2110100	FRONT FRAME COMP.	£2 165,75
# 2	B3J-21447-00 B3J2144700 B3J2144700	BRACKET, FOOTREST	£135,77
# 3	17D-21448-00 17D2144800 17D2144800	BRACKET, FOOTREST	£45,01
# 4	90149-10031 901491003300 9014910031	SCREW	£4,27
# 5	BR9-21190-01 BR92119001 BR92119001	REAR FRAME COMP.	£528,32
# 6	90105-08230 9010508230 9010508230	BOLT, FLANGE	£2,18
# 7	30X-22178-00 30X2217800 30X2217800	TENSIONER	£15,08
# 8	4V4-22184-00 4V42218400 4V42218400	BUSH	Not available	£0,00
# 9	90201-08045 9020108045 9020108045	WASHER, PLATE	£2,75
# 10	90387-08041 9038708041 9038708041	COLLAR	£2,35
# 11	95022-08040 9502208040 9502208040	BOLT, FLANGE	£2,09
# 12	BR9-22178-00 BR92217800 BR92217800	TENSIONER	£26,86
# 13	93300-60839 9330060839 9330060839	BEARING	£9,40
# 14	90387-086N4 90387086N4 90387086N4	COLLAR(1NL)	£3,72
# 15	90105-08232 9010508232 9010508232	BOLT, FLANGE	£1,78
# 16	90185-08009 956170810000 9018508009	NUT, U	£3,55
# 17	90201-08043 9020108043 9020108043	WASHER, PLATE	£0,77
# 18	B3J-21149-00 B3J2114900 B3J2114900	BRACKET, BATTERY BOX	£19,15
# 19	90267-32146 9026732146 9026732146	RIVET, BLIND (2YK)	£1,04
# 20	90105-10361 9010510361 9010510361	BOLT, FLANGE	£7,76
# 21	90179-10658 957041050000 9017910658	NUT, FLANGE(3BM)	£1,20
# 22	90201-10045 9020110045 9020110045	WASHER, PLATE	£2,12
# 23	BR9-21417-00 BR92141700 BR92141700	BRACKET, FRONT LOWER 1	£14,42
# 24	2GB-21418-10 2GB2141810 2GB2141810	BRACKET, FRONT LOWER 2	£35,54
# 25	90105-08143 9010508143 9010508143	BOLT, FLANGE	£2,18
# 26	90105-10176 9010510176 9010510176	BOLT, FLANGE	£7,04
# 27	90179-10658 957041050000 9017910658	NUT, FLANGE(3BM)	£1,20
# 28	90201-10045 9020110045 9020110045	WASHER, PLATE	£2,12
# 29	90105-10189 9010510189 9010510189	BOLT, FLANGE	£3,30
# 30	BR9-21425-00 BR92142500 BR92142500	BRACKET, REAR UPPER 1	£55,44
# 31	BR9-21426-00 BR92142600 BR92142600	BRACKET, REAR UPPER 2	£55,44
# 32	90105-08143 9010508143 9010508143	BOLT, FLANGE	£2,18
# 33	B3J-2147A-00 B3J2147A00 B3J2147A00	GUARD, ENGINE 1	£80,28
# 34	90119-06166 9011906166 9011906166	BOLT, WITH WASHER	£0,83
# 35	1SL-21163-01 1SL2116301 1SL2116301	HOLDER, CLUTCH CABLE	£16,13
# 36	92012-06010 9201206010 9201206010	BOLT, BUTTON HEAD	£0,66
# 37	B7R-21163-00 B7R2116300 B7R2116300	HOLDER, CLUTCH CABLE	£12,54
# 38	92012-06010 9201206010 9201206010	BOLT, BUTTON HEAD	£0,66
# 39	90464-31002 9046431002 9046431002	CLAMP	£4,27
# 40	BR9-2171X-01 BR92171X0200 BR92171X01	COVER, SIDE 6	£5,72
# 41	90269-06081 9026906081 9026906081	RIVET	£1,04
# 42	BR9-24181-00 BR92418100 BR92418100	DAMPER, LOCATING 1	£29,50
# 43	BR9-24182-00 BR92418200 BR92418200	DAMPER, LOCATING 2	£19,49
# 44	BR9-24183-00 BR92418300 BR92418300	DAMPER, LOCATING 3	£14,93
# 45	5ET-28166-10 5ET2816610 5ET2816610	WRENCH, HEXAGON	£34,80
# 46	18P-2467E-00 18P2467E00 18P2467E00	CAP	£1,58
# 47	18P-2464V-00 18P2464V0100 18P2464V00	CASE, CAP	£7,78
# 48	B7R-28199-70 B7R2819970 B7R2819970	MANUAL, OWNER'S	£30,49
# 48	B7R-28199-40 B7R2819940 B7R2819940	MANUAL, OWNER'S	Not available	£0,00

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
