CYLINDER

CRANKSHAFT / PISTON FOR YAMAHA WR 450 F YAMAHA BLUE 2019

VALVE

(1) B3J-11400-00

CRANKSHAFT ASSY

(2) BR9-11412-10

CRANK 1

(3) BR9-11422-00

CRANK 2

(4) 5TG-11681-01

PIN, CRANK 1

(5) 93310-63499

BEARING

(6) 33D-11651-03

ROD, CONNECTING

(7) 93306-30633

BEARING

(7) 93306-30633

BEARING

(8) 2S2-11536-00

GEAR, DRIVE

(9) BR9-11455-00

SHAFT 1

(10) 93306-20335

BEARING(37F)

(10) 93306-20335

BEARING(37F)

(11) 2S2-11531-10

GEAR, BALANCE WEIGHT

(12) 901701417100

NUT, HEXAGON

(13) 90215-14287

WASHER, LOCK(4GA)

(14) 33D-11454-00

WEIGHT 1

(15) 901490608400

SCREW

(16) 33D-11464-00

WEIGHT 2

(17) 90282-05034

KEY, STRAIGHT (3L5)

(18) 90170-10013

NUT

(19) 90215-10009

WASHER, LOCK

(20) BR9-116A0-00

PISTON ASSY

(21) BR9-11631-00

PISTON (STD)

(22) 33D-11603-00

PISTON RING SET (STD)

(23) BR9116331000

PIN, PISTON

(24) 93450-19052

CIRCLIP (2F1)

(24) 93450-19052

CIRCLIP (2F1)

(25) 90280-03006

KEY, WOODRUFF

	Part number	Description	Qty
# 1	B3J-11400-00 B3J1140000 B3J1140000	CRANKSHAFT ASSY	£653,94
# 2	BR9-11412-10 BR91141210 BR91141210	CRANK 1	£321,31
# 3	BR9-11422-00 BR91142200 BR91142200	CRANK 2	£333,83
# 4	5TG-11681-01 5TG1168101 5TG1168101	PIN, CRANK 1	£67,76
# 5	93310-63499 9331063499 9331063499	BEARING	£43,99
# 6	33D-11651-03 33D1165103 33D1165103	ROD, CONNECTING	£97,26
# 7	93306-30633 9330630633 9330630633	BEARING	£67,38
# 8	2S2-11536-00 2S21153600 2S21153600	GEAR, DRIVE	£103,25
# 9	BR9-11455-00 BR91145500 BR91145500	SHAFT 1	£140,11
# 10	93306-20335 9330620335 9330620335	BEARING(37F)	£22,91
# 11	2S2-11531-10 2S21153110 2S21153110	GEAR, BALANCE WEIGHT	£74,21
# 12	901701417100 901701417100 901701417100	NUT, HEXAGON	£3,55
# 13	90215-14287 9021514287 9021514287	WASHER, LOCK(4GA)	£3,96
# 14	33D-11454-00 33D1145400 33D1145400	WEIGHT 1	£65,20
# 15	90149-06083 901490608400 9014906083	SCREW	£1,39
# 16	33D-11464-00 33D1146400 33D1146400	WEIGHT 2	£83,64
# 17	90282-05034 9028205034 9028205034	KEY, STRAIGHT (3L5)	£1,32
# 18	90170-10013 9017010013 9017010013	NUT	£9,71
# 19	90215-10009 9021510009 9021510009	WASHER, LOCK	£9,00
# 20	BR9-116A0-00 BR9116A000 BR9116A000	PISTON ASSY	£215,62
# 21	BR9-11631-00 BR91163100 BR91163100	PISTON (STD)	£136,85
# 22	33D-11603-00 33D1160300 33D1160300	PISTON RING SET (STD)	£66,11
# 23	BR9-11633-00 BR9116331000 BR91163300	PIN, PISTON	£42,77
# 24	93450-19052 9345019052 9345019052	CIRCLIP (2F1)	£1,86
# 25	90280-03006 9028003006 9028003006	KEY, WOODRUFF	£6,94

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
