CAMSHAFT / TIMING CHAIN

WATERPUMP / HOSES FOR YAMAHA VMAX 1700 2012

RADIATOR / HOSES

(1) 2S3-12450-00

IMPELLER SHAFT ASSY

(2) 90201-08067

WASHER, PLATE

(3) 2S3-12459-00

GEAR, IMPELLER SHAFT

(4) 93603-16219

PIN, DOWEL(1HX)

(5) 93306-00105

BRG,R-B 6001 28MM 28G KY

(6) 93102-12106

OIL SEAL (12X22X5-371)

(7) 4C8-12438-00

SEAL, MECHANICAL

(8) 99009-12400

CIRCLIP(10Y)

(9) 93440-07182

CIRCLIP

(10) 902011254100

WASHER, PLATE (525)

(11) 2S3-12422-00

COVER, HOUSING

(12) 2S3-12414-00

GASKET, COVER

(13) 913140602000

BOLT,SOCKET HEAD

(14) 2S3-12483-00

PIPE 3

(15) 932102777800

O-RING(1KT)

(16) 913140601600

BOLT, SOCKET

(17) 2S3-12485-00

PIPE 5

(18) 932101457900

O-RING (26H)

(19) 913140601600

BOLT, SOCKET

(20) 2S3-12481-00

PIPE 1

(21) 932101556600

O-RING (22U)

(21) 932101556600

O-RING (22U)

(22) 913170601600

BOLT,SOCKET

(23) 2S3-12482-00

PIPE 2

(24) 932101556600

O-RING (22U)

(24) 932101556600

O-RING (22U)

(25) 913170601600

BOLT,SOCKET

(26) 2S3-12589-00

HOSE 6

(27) 904502800100

HOSE CLAMP ASSY

(27) 904502800100

HOSE CLAMP ASSY

(28) 2S3-12484-00

PIPE 4

(29) 2S3-12551-00

HOSE 7

(30) 904502800100

HOSE CLAMP ASSY

(31) 90450-32015

HOSE CLAMP ASSY

(32) 2S3-1243E-00

HOSE 2

(33) 904502800100

HOSE CLAMP ASSY

(34) 90450-32015

HOSE CLAMP ASSY

(35) 2S3-12417-00

HOUSING, THERMOSTAT

(36) 5LP124110100

THERMOSTAT

(37) 93210-49046

O-RING (620)

(38) 957800650000

NUT, FLANGE(7NB)

(39) 2S3-12615-00

BOLT

(40) 2S3-12591-00

SUPT, FILLER NECK

(41) 5SL-12462-00

CAP, RADIATOR

(42) 2S3-12443-00

STAY

(43) 950220601200

BOLT, FLANGE

(44) 920140601400

BOLT, BUTTON HEAD(4NK)

(45) 9045022M1400

HOSE CLAMP ASSY(64X)

(46) 9045018M0900

HOSE CLAMP ASSY(63M)

(46) 9045018M0900

HOSE CLAMP ASSY(63M)

(46) 9045018M0900

HOSE CLAMP ASSY(63M)

(47) 2S3-12588-00

HOSE 5

(48) 2S3-12579-00

HOSE 4

	Part number	Description	Qty
# 1	2S3-12450-00 2S31245000 2S31245000	IMPELLER SHAFT ASSY	£99,14
# 2	90201-08067 9020108067 9020108067	WASHER, PLATE	£8,75
# 3	2S3-12459-00 2S31245900 2S31245900	GEAR, IMPELLER SHAFT	£17,38
# 4	93603-16219 9360316219 9360316219	PIN, DOWEL(1HX)	£1,18
# 5	93306-00105 9330600105 9330600105	BRG, R-B 6001 28MM 28G KY	£14,69
# 6	93102-12106 9310212106 9310212106	OIL SEAL (12X22X5-371)	£10,80
# 7	4C8-12438-00 4C81243800 4C81243800	SEAL, MECHANICAL	£42,62
# 8	99009-12400 9900912400 9900912400	CIRCLIP(10Y)	£0,96
# 9	93440-07182 9344007182 9344007182	CIRCLIP	£0,48
# 10	902011254100 902011254100 902011254100	WASHER, PLATE (525)	£4,58
# 11	2S3-12422-00 2S31242200 2S31242200	COVER, HOUSING	£117,20
# 12	2S3-12414-00 2S31241400 2S31241400	GASKET, COVER	£25,49
# 13	90110-06274 913140602000 9011006274	BOLT, SOCKET HEAD	£1,44
# 14	2S3-12483-00 2S31248300 2S31248300	PIPE 3	£77,63
# 15	93210-27194 932102777800 9321027194	O-RING(1KT)	£5,57
# 16	90110-06247 913140601600 9011006247	BOLT, SOCKET	£1,44
# 17	2S3-12485-00 2S31248500 2S31248500	PIPE 5	£48,38
# 18	93210-14104 932101457900 9321014104	O-RING (26H)	£1,02
# 19	90110-06247 913140601600 9011006247	BOLT, SOCKET	£1,44
# 20	2S3-12481-00 2S31248100 2S31248100	PIPE 1	£163,52
# 21	93210-15414 932101556600 9321015414	O-RING (22U)	£1,73
# 22	91312-06016 9131206016	BOLT, SOCKET	Not available	£0,00
# 23	2S3-12482-00 2S31248200 2S31248200	PIPE 2	£148,70
# 24	93210-15414 932101556600 9321015414	O-RING (22U)	£1,73
# 25	91312-06016 9131206016	BOLT, SOCKET	Not available	£0,00
# 26	2S3-12589-00 2S31258900 2S31258900	HOSE 6	£7,44
# 27	90450-28014 904502800100 9045028014	HOSE CLAMP ASSY	£6,14
# 28	2S3-12484-00 2S31248400 2S31248400	PIPE 4	£58,25
# 29	2S3-12551-00 2S31255100 2S31255100	HOSE 7	£14,30
# 30	90450-28014 904502800100 9045028014	HOSE CLAMP ASSY	£6,14
# 31	90450-32015 9045032015 9045032015	HOSE CLAMP ASSY	£6,24
# 32	2S3-1243E-00 2S31243E00 2S31243E00	HOSE 2	£25,03
# 33	90450-28014 904502800100 9045028014	HOSE CLAMP ASSY	£6,14
# 34	90450-32015 9045032015 9045032015	HOSE CLAMP ASSY	£6,24
# 35	2S3-12417-00 2S31241700 2S31241700	HOUSING, THERMOSTAT	£63,82
# 36	5LP-12411-00 5LP124110100 5LP1241100	THERMOSTAT	£44,40
# 37	93210-49046 9321049046 9321049046	O-RING (620)	£3,16
# 38	95702-06500 957800650000 9570206500	NUT, FLANGE(7NB)	£1,55
# 39	2S3-12615-00 2S31261500 2S31261500	BOLT	£16,44
# 40	2S3-12591-00 2S31259100 2S31259100	SUPT, FILLER NECK	£79,19
# 41	5SL-12462-00 5SL1246200 5SL1246200	CAP, RADIATOR	£35,27
# 42	2S3-12443-00 2S31244300 2S31244300	STAY	£31,42
# 43	90105-06081 950220601200 9010506081	BOLT, FLANGE	£0,42
# 44	90111-06054 920140601400 9011106054	BOLT, BUTTON HEAD(4NK)	£1,18
# 45	90450-25037 9045022M1400 9045025037	HOSE CLAMP ASSY(64X)	£7,34
# 46	90450-22001 9045018M0900 9045022001	HOSE CLAMP ASSY(63M)	£7,99
# 47	2S3-12588-00 2S31258800 2S31258800	HOSE 5	£44,29
# 48	2S3-12579-00 2S31257900 2S31257900	HOSE 4	£36,37

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
