FRONT WHEEL

FRONT BRAKE CALIPER FOR YAMAHA VMAX 1700 2012

REAR WHEEL

(1) 2S3-2581T-00

DISK BRAKE ASSY

(2) 2S3-2581U-00

DISC BRAKE ASSY (RIGHT)

(3) 901490613300

SCREW

(3) 901490613300

SCREW

(4) 4C8-2580T-10

CALIPER ASSY (LEFT)

(5) 4C8258020000

PISTON ASSY, CALIPER

(6) 4C8258030000

CALIPER SEAL KIT

(7) 4C8258050000

BRAKE PAD KIT

(8) 4SV-25924-00

PIN, PAD

(9) 4C8-25919-00

SUPPORT, PAD

(10) 2S3-25919-10

SUPPORT, PAD

(11) 3GM-25925-00

CLIP, PAD PIN

(12) 1J3-W0048-00

BLEED SCREW KIT

(13) 5VY-2583B-00

PIN, KNOCK

(14) 2S3-2580U-00

CALIPER ASSY (RIGHT)

(15) 4C8258020000

PISTON ASSY, CALIPER

(16) 4C8258030000

CALIPER SEAL KIT

(17) 4C8258050000

BRAKE PAD KIT

(18) 4SV-25924-00

PIN, PAD

(19) 4C8-25919-00

SUPPORT, PAD

(20) 2S3-25919-10

SUPPORT, PAD

(21) 3GM-25925-00

CLIP, PAD PIN

(22) 5VS-W0048-00

BLEED SCREW KIT

(23) 5VY-2583B-00

PIN, KNOCK

(24) 90105-10397

BOLT, FLANGE

(24) 90105-10397

BOLT, FLANGE

	Part number	Description	Qty
# 1	2S3-2581T-00 2S32581T00 2S32581T00	DISK BRAKE ASSY	£253,52
# 2	2S3-2581U-00 2S32581U00 2S32581U00	DISC BRAKE ASSY (RIGHT)	£253,52
# 3	90149-06132 901490613300 9014906132	SCREW	£4,02
# 4	4C8-2580T-10 4C82580T10 4C82580T10	CALIPER ASSY (LEFT)	£719,23
# 5	4C8-W0057-00 4C8258020000 4C8W005700	PISTON ASSY, CALIPER	£140,11
# 6	4C8-W0047-00 4C8258030000 4C8W004700	CALIPER SEAL KIT	£47,56
# 7	4C8-W0045-00 4C8258050000 4C8W004500	BRAKE PAD KIT	£77,47
# 8	4SV-25924-00 4SV2592400 4SV2592400	PIN, PAD	£11,50
# 9	4C8-25919-00 4C82591900 4C82591900	SUPPORT, PAD	£6,79
# 10	2S3-25919-10 2S32591910 2S32591910	SUPPORT, PAD	£7,28
# 11	3GM-25925-00 3GM2592500 3GM2592500	CLIP, PAD PIN	£6,14
# 12	1J3-W0048-00 1J3W004800 1J3W004800	BLEED SCREW KIT	£11,81
# 13	5VY-2583B-00 5VY2583B00 5VY2583B00	PIN, KNOCK	£13,63
# 14	2S3-2580U-00 2S32580U00 2S32580U00	CALIPER ASSY (RIGHT)	£803,89
# 15	4C8-W0057-00 4C8258020000 4C8W005700	PISTON ASSY, CALIPER	£140,11
# 16	4C8-W0047-00 4C8258030000 4C8W004700	CALIPER SEAL KIT	£47,56
# 17	4C8-W0045-00 4C8258050000 4C8W004500	BRAKE PAD KIT	£77,47
# 18	4SV-25924-00 4SV2592400 4SV2592400	PIN, PAD	£11,50
# 19	4C8-25919-00 4C82591900 4C82591900	SUPPORT, PAD	£6,79
# 20	2S3-25919-10 2S32591910 2S32591910	SUPPORT, PAD	£7,28
# 21	3GM-25925-00 3GM2592500 3GM2592500	CLIP, PAD PIN	£6,14
# 22	5VS-W0048-00 5VSW004800 5VSW004800	BLEED SCREW KIT	£44,29
# 23	5VY-2583B-00 5VY2583B00 5VY2583B00	PIN, KNOCK	£13,63
# 24	90105-10397 9010510397 9010510397	BOLT, FLANGE	£7,44

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
