TAIL LIGHT FOR YAMAHA EC-03 2012

SWITCH / LEVER

(1) 1CB-84710-00

TAILLIGHT UNIT ASSY

(2) 5FC847210000

LENS, TAILLIGHT

(3) 1VJ144620000

SEAL

(4) 977074063000

SCREW, TAPPING(3AH)

(5) 4KLH47142000

BULB (12V-21/5W)

(6) 90480-10517

GROMMET(3GM)

(6) 90480-10517

GROMMET(3GM)

(7) 90387-053H3

COLLAR (26H)

(7) 90387-053H3

COLLAR (26H)

(8) 929900520000

YBS66-5 WASHER, PLAIN

(8) 929900520000

YBS66-5 WASHER, PLAIN

(9) 985170502000

SCREW, PAN HEAD

(9) 985170502000

SCREW, PAN HEAD

(10) 90338-07043

PLUG 288833190000

(10) 90338-07043

PLUG 288833190000

(11) 3Y6-85130-02

REFLECTOR

(12) 902010555600

WASHER PLATE (664)

(13) 95607-05200

NUT, S/L FLANGE

(14) 4AG-85111-00

REFLECTOR, FRONT 1

(14) 4AG-85111-00

REFLECTOR, FRONT 1

(15) 956170610000

NUT, SELF-LOCKING

(15) 956170610000

NUT, SELF-LOCKING

(16) 1CB-84516-00

COVER, TAILLIGHT

(17) 1CB-84782-00

BRACKET 2

(18) 90480-28191

GROMMET (1H3)

(19) 90159-05018

SCREW, WITH WASHER (1T4/2F3)

(19) 90159-05018

SCREW, WITH WASHER (1T4/2F3)

(20) 985170601200

SCREW, PAN

(21) 90201-066G5

WASHER, PLATE (70R)

	Part number	Description	Qty
# 1	1CB-84710-00 1CB8471000 1CB8471000	TAILLIGHT UNIT ASSY	£85,57
# 2	5FL-84721-00 5FL8472100	LENS, TAILLIGHT	Not available	£0,00
# 3	5FL-84723-00 1VJ144620000 5FL8472300	SEAL	£5,32
# 4	97702-40530 977074063000 9770240530	SCREW, TAPPING(3AH)	£1,18
# 5	1A2-84714-41 4KLH47142000 1A28471441	BULB (12V-21/5W)	£0,89
# 6	90480-10517 9048010517 9048010517	GROMMET(3GM)	£2,35
# 7	90387-053H3 90387053H3 90387053H3	COLLAR (26H)	£2,09
# 8	92902-05200 929900520000 9290205200	YBS66-5 WASHER, PLAIN	£0,48
# 9	98502-05020 985170502000 9850205020	SCREW, PAN HEAD	£0,31
# 10	90338-07043 9033807043 9033807043	PLUG 288833190000	£2,09
# 11	3Y6-85130-02 3Y68513002 3Y68513002	REFLECTOR	£16,44
# 12	90201-054K4 902010555600 90201054K4	WASHER PLATE (664)	£2,35
# 13	95607-05200 9560705200 9560705200	NUT, S/L FLANGE	£1,86
# 14	4AG-85111-00 4AG8511100 4AG8511100	REFLECTOR, FRONT 1	£10,88
# 15	95607-06100 956170610000 9560706100	NUT, SELF-LOCKING	£3,30
# 16	1CB-84516-00 1CB8451600 1CB8451600	COVER, TAILLIGHT	£111,32
# 17	1CB-84782-00 1CB8478200 1CB8478200	BRACKET 2	£74,52
# 18	90480-28191 9048028191 9048028191	GROMMET (1H3)	£5,41
# 19	90159-05018 9015905018 9015905018	SCREW, WITH WASHER (1T4/2F3)	£2,09
# 20	98507-06012 9850706012	SCREW, PAN	Not available	£0,00
# 21	90201-066G5 90201066G5 90201066G5	WASHER, PLATE (70R)	£1,06

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
