TAIL LIGHT

SWITCH / LEVER FOR YAMAHA KODIAK 700 2017

ELECTRICAL 1

(1) B16829100100

LEVER HOLDER ASSY (LEFT)

(2) B16-82911-00

HOLDER, LEVER 1

(3) 5TG-82913-00

HOLDER, LEVER LOWER 1

(4) 2HT-83912-01

LEVER 1

(5) 956170610000

NUT, SELF-LOCKING

(6) 90101-05033

BOLT

(7) 901090679900

BOLT (2YK1)

(8) 90123-08002

BOLT

(9) 90179-08030

NUT

(10) B16-25727-00

BRACKET, LEVER

(11) B16-26154-00

STOPPER, LEVER

(11) B16-26154-00

STOPPER, LEVER

(12) 90501-12743

SPRING, COMPRESSION (22N)

(12) 90501-12743

SPRING, COMPRESSION (22N)

(13) 92012-06016

BOLT, BUTTON HEAD

(14) 90338-07007

PLUG

(15) 90501-300A1

SPRING, COMPRESSION

(16) 90201-10035

WASHER, PLATE

(16) 90201-10035

WASHER, PLATE

(17) 99001-08600

CIRCLIP(2R6)

(17) 99001-08600

CIRCLIP(2R6)

(18) 5D3-25689-00

PLATE, GUIDE

(19) B16-26164-00

LEVER 1

(20) 5TG-83923-00

COLLAR, LEVER 2

(21) 92012-06014

BOLT, BUTTON HEAD

(22) B16-2637E-00

CABLE, CONTROL 1

(23) 1S3-83973-11

SWITCH, HANDLE 3

(24) 3B4-83976-00

SWITCH, HANDLE 1

	Part number	Description	Qty
# 1	B16-82910-00 B16829100100 B168291000	LEVER HOLDER ASSY (LEFT)	£46,49
# 2	B16-82911-00 B168291100 B168291100	HOLDER, LEVER 1	£40,38
# 3	5TG-82913-00 5TG8291300 5TG8291300	HOLDER, LEVER LOWER 1	£6,26
# 4	2HT-83912-01 2HT8391201 2HT8391201	LEVER 1	£23,16
# 5	95602-06100 956170610000 9560206100	NUT, SELF-LOCKING	£3,30
# 6	90101-05033 9010105033 9010105033	BOLT	£0,31
# 7	90109-06798 901090679900 9010906798	BOLT (2YK1)	£3,52
# 8	90123-08002 9012308002 9012308002	BOLT	£3,40
# 9	90179-08030 9017908030 9017908030	NUT	£8,15
# 10	B16-25727-00 B162572700 B162572700	BRACKET, LEVER	£37,69
# 11	B16-26154-00 B162615400 B162615400	STOPPER, LEVER	£2,41
# 12	90501-12743 9050112743 9050112743	SPRING, COMPRESSION (22N)	£3,55
# 13	92012-06016 9201206016 9201206016	BOLT, BUTTON HEAD	£0,66
# 14	90338-07007 9033807007 9033807007	PLUG	£2,50
# 15	90501-300A1 90501300A1 90501300A1	SPRING, COMPRESSION	£13,63
# 16	90201-10035 9020110035 9020110035	WASHER, PLATE	£1,20
# 17	99001-08600 9900108600 9900108600	CIRCLIP(2R6)	£1,56
# 18	5D3-25689-00 5D32568900 5D32568900	PLATE, GUIDE	£3,55
# 19	B16-26164-00 B162616400 B162616400	LEVER 1	£35,17
# 20	5TG-83923-00 5TG8392300 5TG8392300	COLLAR, LEVER 2	£9,77
# 21	92012-06014 9201206014 9201206014	BOLT, BUTTON HEAD	£0,66
# 22	B16-2637E-00 B162637E00 B162637E00	CABLE, CONTROL 1	£44,00
# 23	1S3-83973-11 1S38397311 1S38397311	SWITCH, HANDLE 3	£123,34
# 24	3B4-83976-00 3B48397600 3B48397600	SWITCH, HANDLE 1	£47,09
