GEAR SHIFT SELECTOR DRUM / FORKS

GEAR SHIFT SHAFT / LEVER FOR YAMAHA GRIZZLY DIRECTION ASSISTEE EPS 2017

FRAME

Item numbers

LEVER

B16E81980000 B16E81980000

£6,38

Unit Price Incl. Tax

COLLAR, SHIFTER

2MBE84130000 2MBE84130000

£13,93

Unit Price Incl. Tax

WASHER 1

2MBE81370000 2MBE81370000

£1,84

Unit Price Incl. Tax

SPRING

B16E81830000 B16E81830000

£7,48

Unit Price Incl. Tax

WASHER 2

2MBE81380000 2MBE81380000

£1,61

Unit Price Incl. Tax

BOLT 2

2MBE54822000 2MBE54822000

£1,34

Unit Price Incl. Tax

LEVER

2MBE81910000 2MBE81910000

£11,09

Unit Price Incl. Tax

SHIFT SHAFT COMP.

B16E81030000 B16E81030000

£95,81

Unit Price Incl. Tax

SHIFTER BRKT. ASSY

B16E83800000 B16E83800000

£103,82

Unit Price Incl. Tax

OIL SEAL 2

B16E76G30000 B16E76G30000

£9,31

Unit Price Incl. Tax

GASKET

2MBE81460000 2MBE81460000

£0,82

Unit Price Incl. Tax

BOLT 1

2MBE54811000 2MBE54811000

£1,34

Unit Price Incl. Tax

PIN, DOWEL

2MBE84380000 2MBE84380000

£2,65

Unit Price Incl. Tax

SHIFT GUIDE COMP.

28P181040000 28P181040000

£46,82

Unit Price Incl. Tax

WASHER, PLATE

902010603600 902010603600

£0,40

Unit Price Incl. Tax

BOLT, FLANGE

901050617600

901050617500

£1,12

Unit Price Incl. Tax

ROD, SHIFT

B16181150000 B16181150000

£14,30

Unit Price Incl. Tax

NUT (2H9)

901700622800 901700622800

£2,16

Unit Price Incl. Tax

NUT(JN5)

953120670000

953170670000

£0,49

Unit Price Incl. Tax

LEVER COMP. 1

1HPE81900100 1HPE81900100

£30,98

Unit Price Incl. Tax

ARM, SHIFT 2

1HPE81690000 1HPE81690000

£38,72

Unit Price Incl. Tax

CIRCLIP(53L)

990020660000

990010660000

£0,32

Unit Price Incl. Tax

SHAFT, SHIFT

1HPE81250000 1HPE81250000

£10,25

Unit Price Incl. Tax

SPRING, RETURN

1HPE81960000 1HPE81960000

£1,92

Unit Price Incl. Tax

WASHER, PLATE

902010603600 902010603600

£0,40

Unit Price Incl. Tax

BOLT, FLANGE

958120601600

950220601600

£0,49

Unit Price Incl. Tax

KNOB, SHIFT LEVER

28P181740000 28P181740000

£13,97

Unit Price Incl. Tax

RIVET(81E)

902690505500 902690505500

£1,08

Unit Price Incl. Tax

GUIDE, SHIFT

1HPE81720000 1HPE81720000

£14,95

Unit Price Incl. Tax

COVER, DUST

1HPE81540000 1HPE81540000

£3,78

Unit Price Incl. Tax

BOLT

901090604300 901090604300

£1,50

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
