FRAME FOR YAMAHA YFM700R 2013

FRONT FENDER

(1) 1PE-F1101-09

FRONT FRAME COMP.

(2) 1S3-21190-08

REAR FRAME COMP.

(3) 90149-10034

SCREW

(3) 90149-10034

SCREW

(4) 1S3-21315-10

STAY, ENGINE 2

(5) 90105-08142

BOLT, FLANGE

(6) 958171005500

BOLT, FLANGE(87Y)

(7) 90185-10011

NUT, SELF-LOCKING

(8) 1S3-21316-10

STAY, ENGINE 3

(9) 1S3-21317-10

STAY, ENGINE 3

(10) 90105-08142

BOLT, FLANGE

(10) 90105-08142

BOLT, FLANGE

(11) 95812-10110

BOLT, FLANGE

(12) 90185-10011

NUT, SELF-LOCKING

(13) 958171009000

BOLT,FLANGE

(14) 90185-10011

NUT, SELF-LOCKING

(15) 1PE-F1471-00

PROTECTOR, ENGINE

(16) 901090620100

BOLT

(16) 901090620100

BOLT

(17) 90109-06172

BOLT

(18) 5TG-22178-01

TENSIONER

(19) 93300-60804

BEARING (3X3)

(20) 90201-08043

WASHER, PLATE

(20) 90201-08043

WASHER, PLATE

(21) 90387-08064

COLLAR

(22) 958170804500

BOLT, FLANGE(JN5)

(23) 93306-20352

BEARING

(24) 93102-25081

OIL SEAL (25X44X6-810)

(25) 93102-25099

OIL SEAL (25X36X8-334)

(26) 2GU238720000

HOLDER, BEARING

(27) 90338-26004

PLUG

(28) 90338-24260

PLUG

(29) 90338-20183

PLUG(2AK)

(30) 90338-23004

PLUG

(31) 5B4-F1338-00

CLAMP

(32) 90464-20213

CLAMP(4KJ)

(32) 90464-20213

CLAMP(4KJ)

(33) 25G839360100

BAND, SWITCH CORD

(34) 1S3-2140A-00

DAMPER, STOPPER

(35) 1PE-F8100-00

TOOL KIT

(36) 1NV-2811A-01

GAUGE, AIR

(37) 116-82131-00

BAND, BATTERY

	Part number	Description	Qty
# 1	1PE-F1101-09 1PEF110109 1PEF110109	FRONT FRAME COMP.	£3 280,87
# 2	1S3-21190-08 1S32119008 1S32119008	REAR FRAME COMP.	£766,03
# 3	90149-10034 9014910034 9014910034	SCREW	£3,11
# 4	1S3-21315-10 1S32131510 1S32131510	STAY, ENGINE 2	£6,92
# 5	90105-08142 9010508142 9010508142	BOLT, FLANGE	£1,39
# 6	95812-10055 958171005500 9581210055	BOLT, FLANGE(87Y)	£4,58
# 7	90185-10011 9018510011 9018510011	NUT, SELF-LOCKING	£3,90
# 8	1S3-21316-10 1S32131610 1S32131610	STAY, ENGINE 3	£13,43
# 9	1S3-21317-10 1S32131710 1S32131710	STAY, ENGINE 3	£13,43
# 10	90105-08142 9010508142 9010508142	BOLT, FLANGE	£1,39
# 11	95812-10110 9581210110 9581210110	BOLT, FLANGE	£4,84
# 12	90185-10011 9018510011 9018510011	NUT, SELF-LOCKING	£3,90
# 13	95812-10090 958171009000 9581210090	BOLT, FLANGE	£3,55
# 14	90185-10011 9018510011 9018510011	NUT, SELF-LOCKING	£3,90
# 15	1PE-F1471-00 1PEF147100 1PEF147100	PROTECTOR, ENGINE	£30,53
# 16	90109-06198 901090620100 9010906198	BOLT	£5,40
# 17	90109-06172 9010906172 9010906172	BOLT	£1,04
# 18	5TG-22178-01 5TG2217801 5TG2217801	TENSIONER	£9,85
# 19	93300-60804 9330060804 9330060804	BEARING (3X3)	£29,10
# 20	90201-08043 9020108043 9020108043	WASHER, PLATE	£0,77
# 21	90387-08064 9038708064 9038708064	COLLAR	£2,23
# 22	95812-08045 958170804500 9581208045	BOLT, FLANGE(JN5)	£3,55
# 23	93306-20352 9330620352 9330620352	BEARING	£12,23
# 24	93102-25081 9310225081 9310225081	OIL SEAL (25X44X6-810)	£5,60
# 25	93102-25099 9310225099 9310225099	OIL SEAL (25X36X8-334)	£7,90
# 26	5GT-23872-00 2GU238720000 5GT2387200	HOLDER, BEARING	£22,66
# 27	90338-26004 9033826004 9033826004	PLUG	£5,75
# 28	90338-24260 9033824260 9033824260	PLUG	£3,25
# 29	90338-20183 9033820183 9033820183	PLUG(2AK)	£5,50
# 30	90338-23004 9033823004 9033823004	PLUG	£4,76
# 31	5B4-F1338-00 5B4F133800 5B4F133800	CLAMP	£2,09
# 32	90464-20213 9046420213 9046420213	CLAMP(4KJ)	£3,30
# 33	90464-12045 25G839360100 9046412045	BAND, SWITCH CORD	£1,78
# 34	1S3-2140A-00 1S32140A00 1S32140A00	DAMPER, STOPPER	£1,58
# 35	1PE-F8100-00 1PEF810000 1PEF810000	TOOL KIT	£23,24
# 36	1NV-2811A-01 1NV2811A01 1NV2811A01	GAUGE, AIR	£39,31
# 37	116-82131-00 1168213100 1168213100	BAND, BATTERY	£14,18

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the FRAME of your Yamaha YFM700R of 2013. Let us know if you have any questions.
