FRAME

FENDER FOR YAMAHA YZF-R6 2007

SIDE COVER

(1) 2C02151101P0

FENDER, FRONT

(1) 2C02151101P0

FENDER, FRONT

(2) 90111-06043

BOLT

(2) 90111-06043

BOLT

(3) 90480-14003

GROMMET

(3) 90480-14003

GROMMET

(3) 90480-14003

GROMMET

(4) 90387-06057

COLLAR

(4) 90387-06057

COLLAR

(5) 90111-06030

BOLT

(6) 95707-06500

NUT, FLANGE(4MV)

(7) 2C0-8212B-00

BOX, BATTERY 1

(8) 51Y-21639-00

DAMPER 2

(9) 2C0-21649-00

DAMPER

(9) 2C0-21649-00

DAMPER

(9) 2C0-21649-00

DAMPER

(9) 2C0-21649-00

DAMPER

(9) 2C0-21649-00

DAMPER

(10) 2C0-21541-00

DAMPER 1

(11) 133-82131-00

BAND, BATTERY

(12) 90183-04039

NUT, SPRING(47R)

(13) 90338-06018

PLUG (434)

(14) 2C0-821A1-00

SEAT BTRY. ASSY 1

(15) 2C0-821A2-00

SEAT BTRY. ASSY 2

(16) 90109-06171

BOLT

(17) 90269-07010

RIVET

(17) 90269-07010

RIVET

(18) 904641011200

CLAMP(2TV)

(19) 90464-44002

CLAMP

(20) 2C0-82160-00

BATTERY COVER ASSY

(21) 2C0-21376-00

BAND, TOOL

(22) 2C02161101P0

FENDER, REAR

(22) 2C02161101P0

FENDER, REAR

(23) 2C0-21639-00

DAMPER 2

(24) 5GM-27445-00

PLATE 1

(25) 2C0-2162G-00

PLATE 1

(26) 90269-07010

RIVET

(27) 904641519500

CLAMP(4FM)

(28) 90464-13004

CLAMP

(29) 2C0-21131-00

BRACKET

(30) 92017-06016

BOLT, BUTTON HEAD

(31) 5SL-2172E-00

STAY, SIDE COVER 1

(32) 90338-06018

PLUG (434)

(33) 90119-06138

BOLT, WITH WASHER

(34) 2C0216290100

GUARD, MUD

(35) 3Y6-85130-02

REFLECTOR

(36) 95607-05200

NUT, S/L FLANGE

(37) 2C0-21640-00

REAR STAY COMP.

(38) 2C0-2163A-00

COVER, REAR FENDER 1

(39) 2C0-2163E-00

COVER, REAR FENDER 2

(40) 2C0-21669-00

SEAL

(41) 90464-14228

CLAMP(4NX)

(42) 90109-06182

BOLT

(43) 2C0-22250-00-P0

COVER ASSY

(43) 2C0-22250-00-P0

COVER ASSY

(44) 2C0-2177E-00-P0

LID

(44) 2C0-2177E-00-P0

LID

(45) 2C0-2173T-00

TAPE 1

(46) 2C0-22290-00-P0

COVER ASSY 2

(46) 2C0-22290-00-P0

COVER ASSY 2

(47) 2C0-2177J-00-P0

LID 2

(47) 2C0-2177J-00-P0

LID 2

(48) 2C0-2173T-00

TAPE 1

(49) 90269-06001

RIVET

(49) 90269-06001

RIVET

(50) 2C0-28100-00

TOOL KIT

(51) 2C0-28199-F1

OM YZF-R6 '07

(52) 2C0-21370-00

HELMET HANGER ASSY

(53) 2C0-28110-00

TOOL KIT, 2

(54) 4XV-2814F-00

BOX, SPARK PLUG

(55) 4FM-28135-00

SPANNER, SPECIAL

	Part number	Description	Qty
# 1	2C0-21511-00-P0 2C02151101P0 2C02151100P0	FENDER, FRONT	£168,98
# 2	90111-06043 9011106043 9011106043	BOLT	£3,76
# 3	90480-14003 9048014003 9048014003	GROMMET	£1,32
# 4	90387-06057 9038706057 9038706057	COLLAR	£2,35
# 5	90111-06030 9011106030 9011106030	BOLT	£2,23
# 6	95707-06500 9570706500 9570706500	NUT, FLANGE(4MV)	£0,48
# 7	2C0-8212B-00 2C08212B00 2C08212B00	BOX, BATTERY 1	Not available	£0,00
# 8	51Y-21639-00 51Y2163900 51Y2163900	DAMPER 2	£1,18
# 9	2C0-21649-00 2C02164900 2C02164900	DAMPER	£0,31
# 10	2C0-21541-00 2C02154100 2C02154100	DAMPER 1	Not available	£0,00
# 11	133-82131-00 1338213100 1338213100	BAND, BATTERY	£11,99
# 12	90183-04039 9018304039 9018304039	NUT, SPRING(47R)	£6,11
# 13	90338-06018 9033806018 9033806018	PLUG (434)	£4,54
# 14	2C0-821A1-00 2C0821A100 2C0821A100	SEAT BTRY. ASSY 1	Not available	£0,00
# 15	2C0-821A2-00 2C0821A200 2C0821A200	SEAT BTRY. ASSY 2	Not available	£0,00
# 16	90109-06171 9010906171 9010906171	BOLT	£1,69
# 17	90269-07010 9026907010 9026907010	RIVET	£1,37
# 18	90464-12089 904641011200 9046412089	CLAMP(2TV)	£0,66
# 19	90464-44002 9046444002 9046444002	CLAMP	£1,96
# 20	2C0-82160-00 2C08216000 2C08216000	BATTERY COVER ASSY	Not available	£0,00
# 21	2C0-21376-00 2C02137600 2C02137600	BAND, TOOL	Not available	£0,00
# 22	2C0-21611-00-P0 2C02161101P0 2C02161100P0	FENDER, REAR	£251,16
# 23	2C0-21639-00 2C02163900 2C02163900	DAMPER 2	Not available	£0,00
# 24	5GM-27445-00 5GM2744500 5GM2744500	PLATE 1	£0,77
# 25	2C0-2162G-00 2C02162G00 2C02162G00	PLATE 1	£1,69
# 26	90269-07010 9026907010 9026907010	RIVET	£1,37
# 27	90464-13073 904641519500 9046413073	CLAMP(4FM)	£2,09
# 28	90464-13004 9046413004 9046413004	CLAMP	£4,15
# 29	2C0-21131-00 2C02113100 2C02113100	BRACKET	Not available	£0,00
# 30	92017-06016 9201706016 9201706016	BOLT, BUTTON HEAD	£1,20
# 31	5SL-2172E-00 5SL2172E00 5SL2172E00	STAY, SIDE COVER 1	Not available	£0,00
# 32	90338-06018 9033806018 9033806018	PLUG (434)	£4,54
# 33	90119-06138 9011906138 9011906138	BOLT, WITH WASHER	£1,20
# 34	2C0-21629-00 2C0216290100 2C02162900	GUARD, MUD	£77,06
# 35	3Y6-85130-02 3Y68513002 3Y68513002	REFLECTOR	£16,44
# 36	95607-05200 9560705200 9560705200	NUT, S/L FLANGE	£1,86
# 37	2C0-21640-00 2C02164000 2C02164000	REAR STAY COMP.	£199,09
# 38	2C0-2163A-00 2C02163A00 2C02163A00	COVER, REAR FENDER 1	£11,41
# 39	2C0-2163E-00 2C02163E00 2C02163E00	COVER, REAR FENDER 2	£8,90
# 40	2C0-21669-00 2C02166900 2C02166900	SEAL	£0,11
# 41	90464-14228 9046414228 9046414228	CLAMP(4NX)	£5,20
# 42	90109-06182 9010906182 9010906182	BOLT	£12,36
# 43	2C0-22250-00-P0 2C02225000P0 2C02225000P0	COVER ASSY	Not available	£0,00
# 44	2C0-2177E-00-P0 2C02177E00P0 2C02177E00P0	LID	Not available	£0,00
# 45	2C0-2173T-00 2C02173T00 2C02173T00	TAPE 1	£1,56
# 46	2C0-22290-00-P0 2C02229000P0 2C02229000P0	COVER ASSY 2	Not available	£0,00
# 47	2C0-2177J-00-P0 2C02177J00P0 2C02177J00P0	LID 2	Not available	£0,00
# 48	2C0-2173T-00 2C02173T00 2C02173T00	TAPE 1	£1,56
# 49	90269-06001 9026906001 9026906001	RIVET	£1,37
# 50	2C0-28100-00 2C02810000 2C02810000	TOOL KIT	£56,45
# 51	2C0-28199-F1 2C028199F1 2C028199F1	OM YZF-R6 '07	£31,42
# 52	2C0-21370-00 2C02137000 2C02137000	HELMET HANGER ASSY	£35,82
# 53	2C0-28110-00 2C02811000 2C02811000	TOOL KIT, 2	£43,58
# 54	4XV-2814F-00 4XV2814F00 4XV2814F00	BOX, SPARK PLUG	£31,90
# 55	4FM-28135-00 4FM2813500 4FM2813500	SPANNER, SPECIAL	£16,97

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
