SWINGARM / SHOCK ABSORBER

FINAL DRIVE SHAFT / GEAR COUPLING FOR YAMAHA XV535 1989

STEERING

CARTER DE TRANSMISSION AR

2NT461010000 2NT461010000

Not available

BOLT, STUD (5E5)

901161042800

901161036100

£4,48

Unit Price Incl. Tax

BOLT, HEXAGON

901190812600

970170802500

£1,37

Unit Price Incl. Tax

COLLAR, GUIDE

22U461530000 22U461530000

£22,38

Unit Price Incl. Tax

OIL SEAL (30X42X7-1J7)

931013008400 931013008400

£8,05

Unit Price Incl. Tax

BRG, CYL-CAL ROLLER 80G KY

933114372900 933114372900

£85,25

Unit Price Incl. Tax

RACE, INNER

2H7461220000 2H7461220000

£23,45

Unit Price Incl. Tax

BEARING ASSY

933174151000

2H7461020000

£50,47

Unit Price Incl. Tax

SHIM, THRUST (0.30T)

1J717537Y015

1J717537Y030

£3,36

Unit Price Incl. Tax

SHIM, THRUST (0.40T)

1J717537Y040 1J717537Y040

£3,36

Unit Price Incl. Tax

SHIM, THRUST (0.50T)

1J717537Y050 1J717537Y050

£3,36

Unit Price Incl. Tax

BRG, R-B 6305RB1 62MM 245G KY

933063053900

933063053300

£164,92

Unit Price Incl. Tax

RETAINER, BEARING

4H7461250000 4H7461250000

£45,20

Unit Price Incl. Tax

O-RING (4H7)

932106042600 932106042600

£6,30

Unit Price Incl. Tax

OIL SEAL (4H7)

931013809800 931013809800

£8,56

Unit Price Incl. Tax

COLLAR (22U)

90387256G900 90387256G900

Not available

BOLT, STUD (4H7)

901161024900 901161024900

£10,93

Unit Price Incl. Tax

SEAL 1

22U461360000 22U461360000

Not available

HOUSING, BEARING

22U461520000 22U461520000

£92,81

Unit Price Incl. Tax

SHIM, RING GEAR

22U461170025 22U461170025

£3,12

Unit Price Incl. Tax

SHIM, RING GEAR

22U461170030 22U461170030

£3,12

Unit Price Incl. Tax

SHIM, RING GEAR

22U461170040 22U461170040

£3,12

Unit Price Incl. Tax

.COURONNE COURONNE

22U461170050 22U461170050

Not available

BEARING, CYLINDRICAL (22U)

933160130100 933160130100

£127,55

Unit Price Incl. Tax

WASHER, THRUST

22U461180012 22U461180012

£7,46

Unit Price Incl. Tax

WASHER, THRUST

22U461180014 22U461180014

£7,46

Unit Price Incl. Tax

WASHER, THRUST

22U461180016 22U461180016

£7,46

Unit Price Incl. Tax

WASHER, THRUST

22U461180018 22U461180018

£7,46

Unit Price Incl. Tax

WASHER, THRUST

22U461180020 22U461180020

£7,46

Unit Price Incl. Tax

O-RING (22U)

932113956900 932113956900

£10,84

Unit Price Incl. Tax

BOLT, FLANGE(3GD)

901051028500

958171002500

£3,00

Unit Price Incl. Tax

OIL SEAL (22U)

931026527700 931026527700

£10,93

Unit Price Incl. Tax

PLUG, STRAIGHT SCREW(3FA)

11H134550000

903401413200

£3,12

Unit Price Incl. Tax

GASKET

214111980100 214111980100

£3,29

Unit Price Incl. Tax

BREATHER COMP.

2H7175900000 2H7175900000

£12,37

Unit Price Incl. Tax

SEAL, HUB DUST

1J7253190100

1J7253190200

£12,16

Unit Price Incl. Tax

COUPLING, GEAR

22U461230000 22U461230000

£28,68

Unit Price Incl. Tax

ARBRE DE TRANSMISSION

2GV461720000 2GV461720000

Not available

CIRCLIP, TYPE S

934401911200 934401911200

Not available

SEAL 2

22U461370000 22U461370000

Not available

CIRCLIP (537)

934102203900 934102203900

£3,12

Unit Price Incl. Tax

SPRING, COMPRESSION (22U)

905011572200 905011572200

£1,37

Unit Price Incl. Tax

CROSS JOINT COMP.

4X7461800000 4X7461800000

£312,35

Unit Price Incl. Tax

BEARING(2HR)

933112104400

933999992600

£31,33

Unit Price Incl. Tax

CIRCLIP (4X7)

934402008800 934402008800

£2,44

Unit Price Incl. Tax

NUT(3BM)

953111060000

953141060000

£1,49

Unit Price Incl. Tax

YBS67-10 WASHER, SPRING

929011010000

929901010000

£1,21

Unit Price Incl. Tax

COLLERETTE

90387156G800 90387156G800

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the FINAL DRIVE SHAFT / GEAR COUPLING of your Yamaha XV535 of 1989. Let us know if you have any questions.
