FENDER

SIDE COVER FOR YAMAHA XP500 2011

SIDE COVER 2

Item numbers

COVER, SIDE 1

4B52171100P5

4B52171101P5

£172,43

Unit Price Incl. Tax

EMBLEM 3D

5GJ2173B2000 5GJ2173B2000

£56,46

Unit Price Incl. Tax

DAMPER

4B5217170000 4B5217170000

£1,85

Unit Price Incl. Tax

SCREW, TAPPING(4TV)

977025001600

901670507700

£0,47

Unit Price Incl. Tax

NUT, SPRING(1YT)

901830504200 901830504200

£0,47

Unit Price Incl. Tax

COVER, SIDE 2

4B52172100P5

4B52172101P5

£172,43

Unit Price Incl. Tax

EMBLEM 3D

5GJ2173B2000 5GJ2173B2000

£56,46

Unit Price Incl. Tax

DAMPER

4B5217170000 4B5217170000

£1,85

Unit Price Incl. Tax

CLAMP

5Y9124910000 5Y9124910000

£1,43

Unit Price Incl. Tax

SCREW, TAPPING(4TV)

977025001600

901670507700

£0,47

Unit Price Incl. Tax

NUT, SPRING(1YT)

901830504200 901830504200

£0,47

Unit Price Incl. Tax

DAMPER

4B52174X0000 4B52174X0000

£1,28

Unit Price Incl. Tax

DAMPER

4B52174Y0000 4B52174Y0000

£2,00

Unit Price Incl. Tax

DAMPER

4B5217470000 4B5217470000

£1,52

Unit Price Incl. Tax

COVER, TOP

4B52171A00P5

Not available

EMBLEM, YAMAHA

992440008000 992440008000

£19,38

Unit Price Incl. Tax

CLIP

90468040A000 90468040A000

£0,70

Unit Price Incl. Tax

RIVET

902690600800 902690600800

£1,14

Unit Price Incl. Tax

COVER, FLANGE

4B52175N0000 4B52175N0000

£27,85

Unit Price Incl. Tax

NUT, SPRING (6E5)

9018305M0200 9018305M0200

£0,49

Unit Price Incl. Tax

LID, COVER

4B52177B0000 4B52177B0000

£42,61

Unit Price Incl. Tax

RIVET

902690600100 902690600100

£1,48

Unit Price Incl. Tax

RIVET

902690600100 902690600100

£1,48

Unit Price Incl. Tax

COVER, SEAT COMP.

4B52473F0000 4B52473F0000

£56,62

Unit Price Incl. Tax

LID 1

4B52473T0133 4B52473T0133

£141,31

Unit Price Incl. Tax

LEVER, SEAT

4B52477F0000 4B52477F0000

£37,09

Unit Price Incl. Tax

HOOK, SEAT

5GJ247540100 5GJ247540100

£5,98

Unit Price Incl. Tax

SPRING

4HC247580000 4HC247580000

£6,56

Unit Price Incl. Tax

PIN, DOWEL(4HC)

936035019500 936035019500

£3,56

Unit Price Incl. Tax

COVER

4B5242170000

2PW242170000

£7,01

Unit Price Incl. Tax

SCREW, TAPPING

977024001000 977024001000

£0,11

Unit Price Incl. Tax

5GJ247740000 5GJ247740000

£5,22

Unit Price Incl. Tax

REINFORCEMENT

4B5247620000 4B5247620000

£53,66

Unit Price Incl. Tax

SCREW, BIND(6K1)

989020501000

989800501000

£1,26

Unit Price Incl. Tax

NUT, SPRING

90183050A700 90183050A700

£2,35

Unit Price Incl. Tax

SCREW, TAPPING(4TV)

977025001600

901670507700

£0,47

Unit Price Incl. Tax

COVER, SIDE 1

4B5241290133 4B5241290133

£126,70

Unit Price Incl. Tax

COVER, SIDE 2

4B5241390133 4B5241390133

£128,05

Unit Price Incl. Tax

SCREW, TAPPING

977024001000 977024001000

£0,11

Unit Price Incl. Tax

NUT, SPRING

90183040A000 90183040A000

£0,49

Unit Price Incl. Tax

NUT, SPRING(1YT)

901830504200 901830504200

£0,47

Unit Price Incl. Tax

SCREW, TAPPING(4TV)

977025001600

901670507700

£0,47

Unit Price Incl. Tax

BOLT, FLANGE

958020601000

958120601000

£0,49

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the SIDE COVER of your Yamaha XP500 of 2011. Let us know if you have any questions.
