CYLINDER HEAD FOR YAMAHA XV500S 1996

CYLINDER

JEU DE CULASSE

3BM111010100 3BM111010100

Not available

GUIDE, INTAKE VALVE

4H7111331000

4H7111331100

£61,46

Unit Price Incl. Tax

CIRCLIP (1L9)

934401205200 934401205200

£1,37

Unit Price Incl. Tax

JEU DE CULASSE

3BM111011100 3BM111011100

Not available

GUIDE, INTAKE VALVE

4H7111331000

4H7111331100

£61,46

Unit Price Incl. Tax

CIRCLIP (1L9)

934401205200 934401205200

£1,37

Unit Price Incl. Tax

PIN, DOWEL(3BM)

995301701600 995301701600

£3,85

Unit Price Incl. Tax

COLLERETTE

90387226G700 90387226G700

Not available

GASKET (22U)

904302418400 904302418400

£13,37

Unit Price Incl. Tax

GASKET, CYLINDER HEAD 1

22U111810000 22U111810000

Not available

AMORTISSEUR 3

2GV111270000 2GV111270000

Not available

NUT (22U)

901791039500 901791039500

£13,14

Unit Price Incl. Tax

WASHER PLATE 256111740000

902011013100 902011013100

£3,42

Unit Price Incl. Tax

NUT (2Y5)

901791027900 901791027900

£6,08

Unit Price Incl. Tax

ETRIER, COUVERCLE DE CULASSE 2

2GV111420000 2GV111420000

Not available

ETRIER, COUVERCLE DE CULASSE

2GV111520000 2GV111520000

Not available

NUT(55X)

957070850000

901790849100

£2,26

Unit Price Incl. Tax

WASHER, PLATE (33N)

90201094G100 90201094G100

£2,44

Unit Price Incl. Tax

BOLT, SOCKET

913140803000 913140803000

£1,75

Unit Price Incl. Tax

BOLT, STUD 3

956170863000 956170863000

£3,67

Unit Price Incl. Tax

COUVERCLE LATERAL DE CULASSE 1

2GV111850000 2GV111850000

Not available

COUVERCLE LATERAL DE CULASSE 4

2GV1111H0000 2GV1111H0000

Not available

PLATE, BREATHER

22U111650000 22U111650000

£21,36

Unit Price Incl. Tax

O-RING (22U)

932108956800 932108956800

£7,68

Unit Price Incl. Tax

DURITE, DE RENIFLARD 1

2GV111660000 2GV111660000

Not available

CLIP (371)

904671401500 904671401500

£2,16

Unit Price Incl. Tax

O-RING (22U)

932110061200 932110061200

£9,78

Unit Price Incl. Tax

BOLT, SOCKET HEAD

913140602500 913140602500

£1,49

Unit Price Incl. Tax

COVER, CYLINDER HEAD SIDE 2

22U111860000

22U111860100

£21,16

Unit Price Incl. Tax

COVER, CYLINDER HEAD SIDE 3

22U111870000

22U111870100

£28,68

Unit Price Incl. Tax

O-RING (4X7)

932106244600 932106244600

£3,98

Unit Price Incl. Tax

BOLT, HEXAGON

970270601600

970170601600

£0,94

Unit Price Incl. Tax

WASHER(6TA)

929070660000 929070660000

£0,49

Unit Price Incl. Tax

BOULON, RACCORD

904011607300 904011607300

Not available

GASKET (4X7)

904301716800 904301716800

£4,00

Unit Price Incl. Tax

PLATE

22U1111F0100 22U1111F0100

£3,67

Unit Price Incl. Tax

WASHER, LOCK

902150822900 902150822900

£3,42

Unit Price Incl. Tax

BOLT (26M)

901090878200 901090878200

£3,67

Unit Price Incl. Tax

BOLT (26M)

901090878100 901090878100

£3,85

Unit Price Incl. Tax

PLUG, SPARK (W20EPR-U)

947010022800 947010022800

Not available

PLUG, SPARK (BPR6ES)

947010023400 947010023400

£7,42

Unit Price Incl. Tax

COUVERCLE LATERAL DE CULASSE 2

2NT111860000 2NT111860000

Not available

COUVERCLE COMPLET 1

2NT1110M0000 2NT1110M0000

Not available

COUVERCLE LATERAL DE CULASSE 3

2NT111870000 2NT111870000

Not available

GROMMET

904801841100 904801841100

£4,69

Unit Price Incl. Tax

GROMMET(2GV)

904801947100 904801947100

Not available

BOLT, HEXAGON SOCKET HEAD(2GV)

901100619800 901100619800

£9,44

Unit Price Incl. Tax

COLLAR (8A7)

903870651800 903870651800

£2,71

Unit Price Incl. Tax

COLLERETTE

90387072W200 90387072W200

Not available

WASHER, PLATE (J10)

902010669700 902010669700

£1,37

Unit Price Incl. Tax

GASKET

3BT111950000 3BT111950000

Not available

GASKET, CYLINDER HEAD SIDE

3BT111960000

Not available

BOLT, HEXAGON DEEP RECESS

970240601600

97D950601600

£0,38

Unit Price Incl. Tax

WASHER, PLAIN (646)

929900660000 929900660000

£0,49

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the CYLINDER HEAD of your Yamaha XV500S of 1996. Let us know if you have any questions.
