SWINGARM FOR YAMAHA SR500 1988

STEERING

(1) 3H0221100100

REAR ARM COMP.

(2) 33Y-22124-00-00

BUSH 2

(3) 93317-22208-00

BRG,CYL-CAL ROLLER 28.5G NT

(4) 93342-22205-00

BEARING, THRUST

(5) 902012228404

WASHER, PLATE

(6) 2K8-22129-00-00

COVER, THRUST 2

(7) 431-22151-03-00

SEAL, GUARD

(8) 93108-35004-00

OIL SEAL (35X41.5X8-483)

(9) 33Y-22141-01-00

SHAFT, PIVOT

(10) 90179-16256-00

NUT (2J2)

(11) 2J2223110100

CHAIN CASE

(12) 97D950601600

BOLT, HEXAGON DEEP RECESS

(13) 929950610000

WASHER(6A1)

(14) 970170602000

BOLT, HEXAGON

(15) 904801301400

GROMMET

(16) 90387060A300

COLLAR (3H5)

(17) 90201-06066-00

WASHER, PLATE 1012832300

(18) 950240601000

BOLT, FLANGE(2UJ)

(19) 48U-22210-00-93

AMORTISSEUR, ARRIERE

(20) 90201-14215-00

WASHER PLATE 148272190000

(21) 90201-10696-00

WASHER, PLATE (2J2)

(22) 90201-10696-00

WASHER, PLATE (2J2)

(23) 90176-10009-00

NUT, CAP (371)

(24) 901761000900

NUT, CAP (371)

	Part number	Description	Qty
# 1	3H0-22110-01-33 3H0221100100 3H0221100133	REAR ARM COMP.	£313,81
# 2	33Y-22124-00-00 33Y221240000 33Y221240000	BUSH 2	£73,19
# 3	93317-22208-00 933172220800 933172220800	BRG, CYL-CAL ROLLER 28.5G NT	£31,38
# 4	93342-22205-00 933422220500 933422220500	BEARING, THRUST	£78,92
# 5	648-45533-00-03 902012228404 648455330003	WASHER, PLATE	£2,28
# 6	2K8-22129-00-00 2K8221290000 2K8221290000	COVER, THRUST 2	£14,18
# 7	431-22151-03-00 431221510300 431221510300	SEAL, GUARD	£8,23
# 8	93108-35004-00 931083500400 931083500400	OIL SEAL (35X41.5X8-483)	£6,67
# 9	33Y-22141-01-00 33Y221410100 33Y221410100	SHAFT, PIVOT	£66,25
# 10	90179-16256-00 901791625600 901791625600	NUT (2J2)	£15,36
# 11	2J2-22311-01-93 2J2223110100 2J2223110193	CHAIN CASE	£47,21
# 12	97313-06016-00 97D950601600 973130601600	BOLT, HEXAGON DEEP RECESS	£0,37
# 13	92990-06100-00 929950610000 929900610000	WASHER(6A1)	£0,16
# 14	97001-06020-00 970170602000 970010602000	BOLT, HEXAGON	£1,44
# 15	90480-13197-00 904801301400 904801319700	GROMMET	£1,78
# 16	90387-06216-00 90387060A300 903870621600	COLLAR (3H5)	£2,18
# 17	90201-06066-00 902010606600 902010606600	WASHER, PLATE 1012832300	£2,09
# 18	95023-06010-00 950240601000 950230601000	BOLT, FLANGE(2UJ)	£0,77
# 19	48U-22210-00-93 48U222100093 48U222100093	AMORTISSEUR, ARRIERE	Not available	£0,00
# 20	90201-14215-00 902011421500 902011421500	WASHER PLATE 148272190000	£1,86
# 21	90201-10696-00 902011069600 902011069600	WASHER, PLATE (2J2)	£3,30
# 22	90201-10696-00 902011069600 902011069600	WASHER, PLATE (2J2)	£3,30
# 23	90176-10009-00 901761000900 901761000900	NUT, CAP (371)	£3,72
# 24	90176-10013-00 901761000900 901761001300	NUT, CAP (371)	£3,72

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the SWINGARM of your Yamaha SR500 of 1988. Let us know if you have any questions.
