SIDE COVER - OIL TANK

SWINGARM FOR YAMAHA XT500 1986

REAR SHOCK ABSORBER

BRAS ARRIERE COMP.

43F221100100 43F221100100

Not available

EMBLEME, BRAS ARRIERE

46X2218A0000 46X2218A0000

Not available

BEARING, CYLINDRICAL (23X)

933173223100 933173223100

£33,89

Unit Price Incl. Tax

BUSH, SOLID (23X)

903802211100 903802211100

£15,95

Unit Price Incl. Tax

OIL SEAL (23X)

931062201900 931062201900

£5,81

Unit Price Incl. Tax

COLLIER, D ENTRETOISE

2K6221260100 2K6221260100

Not available

OIL SEAL (35X41.5X8-483)

931083500400 931083500400

£6,91

Unit Price Incl. Tax

WASHER

90201244A800

3YF221490000

£8,04

Unit Price Incl. Tax

BAGUE

34L221230000 34L221230000

Not available

BAGUE

34L221240000 34L221240000

Not available

JOINT, PROTECTEUR

5X6221510000 5X6221510000

Not available

COLLAR (5X6)

90387440G300 90387440G300

£10,48

Unit Price Incl. Tax

PROTECTEUR, CHAINE

34L221530000 34L221530000

Not available

BOLT, FLANGE

958010605000

958170605000

£1,92

Unit Price Incl. Tax

NUT, FLANGE(7NB)

957010650000

957800650000

£1,61

Unit Price Incl. Tax

PROTECTOR, CHAIN

34L221470000 34L221470000

£49,73

Unit Price Incl. Tax

BOULON, AVEC RONDELLE

901190610100 901190610100

Not available

BRAS DE LIAISON

34L2217A0000 34L2217A0000

Not available

PLOT

903381409500 903381409500

Not available

BUSH, SOLID (5X6)

903801409500 903801409500

Not available

COVER, THRUST 1

34L221280000 34L221280000

£11,12

Unit Price Incl. Tax

BOULON

90109120A300 90109120A300

Not available

RONDELLE, PLATE

90201140G900 90201140G900

Not available

WASHER, PLATE (8K2)

90201120A500 90201120A500

£4,81

Unit Price Incl. Tax

NUT, SELF LOCKING (23X)

901851211900 901851211900

£10,10

Unit Price Incl. Tax

ROD, CONNECTING 1

34L2217F0000 34L2217F0000

Not available

BEARING, CYLINDRICAL (23X)

933153173200 933153173200

£39,73

Unit Price Incl. Tax

COLLAR (23X)

90387121H100 90387121H100

£16,06

Unit Price Incl. Tax

COVER, THRUST 2

23X221290000

55K221290000

£12,94

Unit Price Incl. Tax

BOULON

901091075900 901091075900

Not available

WASHER, PLATE(6TC)

90201100E900

9020110M0500

£3,64

Unit Price Incl. Tax

NUT, SELF LOCKING (23X)

901851012000 901851012000

£7,03

Unit Price Incl. Tax

BUSH (34L)

903862012300 903862012300

£23,45

Unit Price Incl. Tax

COLLAR (34L)

90387122J600 90387122J600

£19,72

Unit Price Incl. Tax

BOLT(2VG)

901091076000

Not available

WASHER (7A9)

90201100F700 90201100F700

£3,12

Unit Price Incl. Tax

NUT, SELF LOCKING (23X)

901851012000 901851012000

£7,03

Unit Price Incl. Tax

NIPPLE, GREASE

937000600500 937000600500

£6,32

Unit Price Incl. Tax

NIPPLE, GREASE(6A1)

937000600400

9370006M0300

£5,00

Unit Price Incl. Tax

CASE, CHAIN

34L223110100

3TB223110100

£56,06

Unit Price Incl. Tax

WASHER, PLATE (4L0)

90201062A800 90201062A800

£0,49

Unit Price Incl. Tax

SCREW, PAN

925060601200

Not available

WASHER, SPRING

929060610000

929070610000

£0,61

Unit Price Incl. Tax

AXE, PIVOT

34K221410100 34K221410100

Not available

WASHER (525)

902011523800 902011523800

£1,92

Unit Price Incl. Tax

NUT, SELF-LOCKING (1J7)

901851407000 901851407000

£7,45

Unit Price Incl. Tax

SUPPORT

34L2216G0000 34L2216G0000

Not available

SOUFFLET, CAOUTCHOUC

34L221890000 34L221890000

Not available

RIVET, BLIND (2YK)

902673207200

902673214600

£1,08

Unit Price Incl. Tax

CAP

34L221170000 34L221170000

£12,37

Unit Price Incl. Tax

WASHER, PLATE (5Y1)

90201251F600 90201251F600

£1,92

Unit Price Incl. Tax

GRAISSEUR

937000800500 937000800500

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the SWINGARM of your Yamaha XT500 of 1986. Let us know if you have any questions.
