SWINGARM FOR YAMAHA XT500 1986

STEERING

BRAS ARRIERE COMP.

2H7221100033 2H7221100033

Not available

BEARING, THRUST

933422220500 933422220500

£82,28

Unit Price Incl. Tax

BRG, CYL-CAL ROLLER 28.5G NT

933172220800 933172220800

£32,71

Unit Price Incl. Tax

BUSH 2

483221240000 483221240000

Not available

WASHER, PLATE

648455330003

902012228404

£2,46

Unit Price Incl. Tax

COVER, THRUST 2

2K8221290000 2K8221290000

£15,29

Unit Price Incl. Tax

SEAL, GUARD

431221510300 431221510300

£8,88

Unit Price Incl. Tax

OIL SEAL (35X41.5X8-483)

931083500400 931083500400

£7,07

Unit Price Incl. Tax

AXE, PIVOT

583221410100 583221410100

Not available

NUT, U (6TD)

956011610000

956171610000

£16,99

Unit Price Incl. Tax

WASHER (517 CLUTCH)

902081601900 902081601900

£3,25

Unit Price Incl. Tax

PROTECTEUR, CHAINE

1U6223180033 1U6223180033

Not available

BOLT, HEXAGON

973010801600

970130801600

£1,28

Unit Price Incl. Tax

YBS67-8 WASHER, SPRING

929900810000 929900810000

£0,49

Unit Price Incl. Tax

BOLT, HEXAGON DEEP RECESS

973010601600

97D950601600

£0,38

Unit Price Incl. Tax

WASHER(6A1)

929900610000

929950610000

£0,16

Unit Price Incl. Tax

CARTER, CHAINE

1U6223110033 1U6223110033

Not available

SCREW, PAN HEAD(6B0)

985010501600

978850501600

£2,26

Unit Price Incl. Tax

VIS, TETE TRONCONIQUE

985010510000 985010510000

Not available

SCREW, PAN HEAD(6B0)

985010501600

978850501600

£2,26

Unit Price Incl. Tax

YBS67-5 WASHER, SPRING

929010510000

929900510000

£0,49

Unit Price Incl. Tax

SPACER 214223170000

905600500100 905600500100

£2,54

Unit Price Incl. Tax

COLLAR (3L6)

903870500900

903870676100

£2,26

Unit Price Incl. Tax

WASHER, PLATE

902010640700

902010674700

£3,25

Unit Price Incl. Tax

GROMMET(JG1)

904801218800

904801252900

£1,43

Unit Price Incl. Tax

GROMMET (1U6)

904800821600 904800821600

£4,48

Unit Price Incl. Tax

NIPPLE, GREASE(6A1)

937000600400

9370006M0300

£5,22

Unit Price Incl. Tax

ARM, CHAIN TENSIONER

2Y0221790000 2Y0221790000

Not available

TENSIONER

2N0221780000 2N0221780000

£12,41

Unit Price Incl. Tax

OIL SEAL (2K8)

931041404400

931091402100

£5,63

Unit Price Incl. Tax

SCREW, PANHEAD (EG9)

985010504000

985800554000

£1,91

Unit Price Incl. Tax

YBS67-5 WASHER, SPRING

929010510000

929900510000

£0,49

Unit Price Incl. Tax

RESSORT, TORSION

905083538700 905083538700

Not available

BOLT (1J4)

901091053300

901091048300

£9,26

Unit Price Incl. Tax

WASHER, PLATE (3X3)

902011421800

902011579700

£2,26

Unit Price Incl. Tax

REAR FOOTREST ASSY

1E6274300000

120274300200

£34,31

Unit Price Incl. Tax

FOOTREST, REAR 1

120274310000

2GV274310000

£47,05

Unit Price Incl. Tax

BRACKET, REAR FOOTREST

120274320200 120274320200

£4,67

Unit Price Incl. Tax

COVER, REAR FOOTREST

120274330000 120274330000

£4,67

Unit Price Incl. Tax

WASHER, PLATE (888)

902012027900 902012027900

£0,49

Unit Price Incl. Tax

.BOULON, A GOUPILLE BOULON, A GOUPILLE

902400506200 902400506200

Not available

NUT, HEXAGON SMALL

953011270000

953171270000

£2,14

Unit Price Incl. Tax

PIN, COTTER (648)

914012001500

914902001500

£1,82

Unit Price Incl. Tax

WASHER, PLATE(J41)

90201062G300

902010604900

£1,43

Unit Price Incl. Tax

SHOCK ABSORBER ASSY, REAR

3H7222100000 3H7222100000

Not available

.COUVERCLE COUVERCLE

1T1222110000 1T1222110000

Not available

.RESSORT RESSORT

1T1222120000 1T1222120000

Not available

.GUIDE, RESSORT GUIDE, RESSORT

583222140000 583222140000

Not available

BOLT (583 REAR CUSHION)

901091042000 901091042000

£4,94

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the SWINGARM of your Yamaha XT500 of 1986. Let us know if you have any questions.
