CRANKCASE

STARTER MOTOR FOR YAMAHA CY50R 1996

STARTER CLUTCH

GEAR 1

4JP155130000 4JP155130000

£41,80

Unit Price Incl. Tax

BEARING

93310257R100

933102571200

£24,91

Unit Price Incl. Tax

BOSS, GEAR

3KJ155280000 3KJ155280000

£10,01

Unit Price Incl. Tax

STARTER CLUTCH ASSY

3VL155700000 3VL155700000

£49,79

Unit Price Incl. Tax

IDLE GEAR ASSY

4JP156500000 4JP156500000

Not available

SHAFT

50M133420000

Not available

WASHER, PLATE 2562171800

902010808800 902010808800

£2,16

Unit Price Incl. Tax

PLATE, IDLE GEAR

3KJ155320000 3KJ155320000

Not available

SCREW, PAN

985070601200

Not available

BOLT, SOCKET

913180602000

913170602000

£1,49

Unit Price Incl. Tax

KICK SHAFT ASSY

3KJ156010000 3KJ156010000

Not available

SPRING, TORSION (32N)

905083260900 905083260900

£12,37

Unit Price Incl. Tax

BUSH, SOLID

903801508300

903801581700

£2,20

Unit Price Incl. Tax

WASHER, PLATE (5G3)

90201155G500

90201154E900

£2,16

Unit Price Incl. Tax

CIRCLIP(1AR)

990091540000 990091540000

£2,16

Unit Price Incl. Tax

KICK START

4CUX56200000 4CUX56200000

Not available

BOLT, HEXAGON

973160602500

970170602500

£1,14

Unit Price Incl. Tax

KICK PINION ASSY

3KJ156300000 3KJ156300000

Not available

CLIP

32N156730000 32N156730000

£3,67

Unit Price Incl. Tax

JONC

3KJ156730000 3KJ156730000

Not available

O-RING (35R)

932102361400 932102361400

£0,95

Unit Price Incl. Tax

FIL

3WGH25410000 3WGH25410000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the STARTER MOTOR of your Yamaha CY50R of 1996. Let us know if you have any questions.
