STARTER MOTOR

STARTER CLUTCH FOR YAMAHA TTR 50 ELECTRIC START 2013

TRANSMISSION

(1) 1P6-E6116-00

COLLAR 1

(2) 1P6-E6111-10

GEAR, PRIMARY DRIVE

(3) 90201-17801

WASHER, PLATE

(4) 1P6-E6311-00

HOUSING, CLUTCH

(5) 1P6-E6818-01

GEAR, OUTER DRIVE

(6) 1P6-E6571-01

BOSS, CLUTCH

(7) 1P6-E6324-00

PLATE, CLUTCH 1

(8) 1P6-E6330-00

PLATE, FRICTION 2

(9) 1P6-E6325-00

PLATE, CLUTCH 2

(10) 1P6-E6326-00

PLATE, CLUTCH 3

(11) 1P6-E6819-00

CIRCLIP, CLUTCH

(12) 1P6-E6821-00

SPPRING, DISK

(13) 1P6-E6822-10

SPRING, GARTER

(14) 90179-14802

NUT

(15) 90208-14033

WASHER, CONICAL SPRING

(16) 1P6-E6170-00

PRIMARY DRIVEN GEAR COMP.

(17) 1P6-E6377-00

NUT, LOCK

(18) 1P6-E6378-00

WASHER, LOCK

(19) 1P6-E6551-00

PLATE, PRESSURE 1

(20) 1P6-E6552-00

PIN, GUIDE

(21) 1P6-E6152-00

BUSH

(22) 1P6-E6125-00

ABSORBER 2

(23) 93306-900Y0

BEARING

(24) 90201-05810

WASHER, PLATE

(25) 98512-05012

SCREW, PAN HEAD

	Part number	Description	Qty
# 1	1P6-E6116-00 1P6E611600 1P6E611600	COLLAR 1	£13,16
# 2	1P6-E6111-10 1P6E611110 1P6E611110	GEAR, PRIMARY DRIVE	£86,77
# 3	90201-17801 9020117801 9020117801	WASHER, PLATE	£2,12
# 4	1P6-E6311-00 1P6E631100 1P6E631100	HOUSING, CLUTCH	£114,52
# 5	1P6-E6818-01 1P6E681801 1P6E681801	GEAR, OUTER DRIVE	£158,02
# 6	1P6-E6571-01 1P6E657101 1P6E657101	BOSS, CLUTCH	£126,92
# 7	1P6-E6324-00 1P6E632400 1P6E632400	PLATE, CLUTCH 1	£36,92
# 8	1P6-E6330-00 1P6E633000 1P6E633000	PLATE, FRICTION 2	£87,73
# 9	1P6-E6325-00 1P6E632500 1P6E632500	PLATE, CLUTCH 2	£19,26
# 10	1P6-E6326-00 1P6E632600 1P6E632600	PLATE, CLUTCH 3	£30,77
# 11	1P6-E6819-00 1P6E681900 1P6E681900	CIRCLIP, CLUTCH	£34,40
# 12	1P6-E6821-00 1P6E682100 1P6E682100	SPPRING, DISK	£59,29
# 13	1P6-E6822-10 1P6E682210 1P6E682210	SPRING, GARTER	£59,64
# 14	90179-14802 9017914802 9017914802	NUT	£4,02
# 15	90208-14033 9020814033 9020814033	WASHER, CONICAL SPRING	£3,01
# 16	1P6-E6170-00 1P6E617000 1P6E617000	PRIMARY DRIVEN GEAR COMP.	£238,42
# 17	1P6-E6377-00 1P6E637700 1P6E637700	NUT, LOCK	£2,12
# 18	1P6-E6378-00 1P6E637800 1P6E637800	WASHER, LOCK	£2,12
# 19	1P6-E6551-00 1P6E655100 1P6E655100	PLATE, PRESSURE 1	£22,48
# 20	1P6-E6552-00 1P6E655200 1P6E655200	PIN, GUIDE	£2,12
# 21	1P6-E6152-00 1P6E615200 1P6E615200	BUSH	£22,94
# 22	1P6-E6125-00 1P6E612500 1P6E612500	ABSORBER 2	£1,39
# 23	93306-900Y0 93306900Y0 93306900Y0	BEARING	£26,59
# 24	90201-05810 9020105810 9020105810	WASHER, PLATE	£0,66
# 25	98512-05012 9851205012 9851205012	SCREW, PAN HEAD	£1,06

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the STARTER CLUTCH of your Yamaha TTR 50 ELECTRIC START of 2013. Let us know if you have any questions.
