INTAKE

CARBURETOR FOR YAMAHA DT50MX 1986

EXHAUST

(1) 5N6-14301-00-00

CARBURATEUR COMPLET 1

(2) 367-14169-00-00

.COUVERCLE COUVERCLE

(3) 288-14124-00-00

.VIS, REGLAGE DE CABLE VIS, REGLAGE DE CABLE

(4) 85L141610000

NUT, CABLE ADJUSTING

(5) 4U1-14126-00-00

.JOINT JOINT

(6) 1G3-14312-10-00

.BOISSEAU 1 BOISSEAU 1

(7) 367-14331-00-00

.RESSORT, BOISSEAU RESSORT, BOISSEAU

(8) 367-14136-02-00

.SIEGE, RESSORT SIEGE, RESSORT

(9) 2T4-14336-10-00

.AIGUILLE AIGUILLE

(10) 288-14137-00-00

.JONC JONC

(11) 5L3-14341-00-00

.PUITS D AIGUILLE PUITS D AIGUILLE

(12) 288-14343-56-00

.GICLEUR, PRINCIPAL GICLEUR, PRINCIPAL

(12) 288-14343-57-00

JET, MAIN (# 114)

(12) 288-14343-58-00

JET, MAIN (# 116)

(13) 396-14342-20-00

.GICLEUR, RALENTI GICLEUR, RALENTI

(14) 367-14390-14-00

VALVE SEAT ASSY

(15) 367-14195-00-00

WASHER, VALVE SEAT

(16) 367-14386-00-00

.AXE, FLOTTEUR AXE, FLOTTEUR

(17) 367-14385-00-00

FLOAT

(18) 367-14381-25-00

.CORPS, CUVE DE FLOTTEUR CORPS, CUVE DE FLOTTEUR

(19) 4U1-14384-00-00

GASKET, FLOAT CHAMBER

(20) 1YU141030000

THROTTLE SCREW SET

(21) 646-14212-01-00

SPRING, PILOT ADJUSTING

(22) 367-14323-00-00

.VIS DE DOSEUR D AIR VIS DE DOSEUR D AIR

(23) 367-14337-00-00

.GICLEUR A AIR, PRINCIPAL GICLEUR A AIR, PRINCIPAL

(24) 367-14371-00-00

.PLONGEUR, STARTER PLONGEUR, STARTER

(25) 367-14335-00-00

.RESSORT, PLONGEUR RESSORT, PLONGEUR

(26) 367-14374-00-00

.COUVERCLE PLONGEUR COUVERCLE PLONGEUR

(27) 626-14373-10-00

.COUVERCLE DE PLONGEUR COUVERCLE DE PLONGEUR

(28) 367-14375-01-00

.LEVIER, STARTER LEVIER, STARTER

(29) 367-14377-00-00

.BUTEE BUTEE

(30) 985170401200

SCREW, PAN HEAD

(31) 970170602500

BOLT, HEXAGON

(32) 367143960000

PIPE, OVER FLOW

(33) 5N6-14349-00-00

.DURITE DURITE

	Part number	Description	Qty
# 1	5N6-14301-00-00 5N6143010000 5N6143010000	CARBURATEUR COMPLET 1	Not available	£0,00
# 2	367-14169-00-00 367141690000 367141690000	.COUVERCLE COUVERCLE	Not available	£0,00
# 3	288-14124-00-00 288141240000 288141240000	.VIS, REGLAGE DE CABLE VIS, REGLAGE DE CABLE	Not available	£0,00
# 4	288-14161-00-00 288141610000	NUT, CABLE ADJUSTING	Not available	£0,00
# 5	4U1-14126-00-00 4U1141260000 4U1141260000	.JOINT JOINT	Not available	£0,00
# 6	1G3-14312-10-00 1G3143121000 1G3143121000	.BOISSEAU 1 BOISSEAU 1	Not available	£0,00
# 7	367-14331-00-00 367143310000 367143310000	.RESSORT, BOISSEAU RESSORT, BOISSEAU	Not available	£0,00
# 8	367-14136-02-00 367141360200 367141360200	.SIEGE, RESSORT SIEGE, RESSORT	Not available	£0,00
# 9	2T4-14336-10-00 2T4143361000 2T4143361000	.AIGUILLE AIGUILLE	Not available	£0,00
# 10	288-14137-00-00 288141370000 288141370000	.JONC JONC	Not available	£0,00
# 11	5L3-14341-00-00 5L3143410000 5L3143410000	.PUITS D AIGUILLE PUITS D AIGUILLE	Not available	£0,00
# 12	288-14343-56-00 288143435600 288143435600	.GICLEUR, PRINCIPAL GICLEUR, PRINCIPAL	Not available	£0,00
# 12	288-14343-58-00 288143435800 288143435800	JET, MAIN (# 116)	£10,44
# 12	288-14343-57-00 288143435700 288143435700	JET, MAIN (# 114)	Not available	£0,00
# 13	396-14342-20-00 396143422000 396143422000	.GICLEUR, RALENTI GICLEUR, RALENTI	Not available	£0,00
# 14	367-14390-14-00 367143901400 367143901400	VALVE SEAT ASSY	£54,31
# 15	367-14195-00-00 367141950000 367141950000	WASHER, VALVE SEAT	£2,09
# 16	367-14386-00-00 367143860000 367143860000	.AXE, FLOTTEUR AXE, FLOTTEUR	Not available	£0,00
# 17	367-14385-00-00 367143850000 367143850000	FLOAT	£52,87
# 18	367-14381-25-00 367143812500 367143812500	.CORPS, CUVE DE FLOTTEUR CORPS, CUVE DE FLOTTEUR	Not available	£0,00
# 19	4U1-14384-00-00 4U1143840000 4U1143840000	GASKET, FLOAT CHAMBER	£13,39
# 20	367-14211-00-00 1YU141030000 367142110000	THROTTLE SCREW SET	£12,62
# 21	646-14212-01-00 646142120100 646142120100	SPRING, PILOT ADJUSTING	£2,90
# 22	367-14323-00-00 367143230000 367143230000	.VIS DE DOSEUR D AIR VIS DE DOSEUR D AIR	Not available	£0,00
# 23	367-14337-00-00 367143370000 367143370000	.GICLEUR A AIR, PRINCIPAL GICLEUR A AIR, PRINCIPAL	Not available	£0,00
# 24	367-14371-00-00 367143710000 367143710000	.PLONGEUR, STARTER PLONGEUR, STARTER	Not available	£0,00
# 25	367-14335-00-00 367143350000 367143350000	.RESSORT, PLONGEUR RESSORT, PLONGEUR	Not available	£0,00
# 26	367-14374-00-00 367143740000 367143740000	.COUVERCLE PLONGEUR COUVERCLE PLONGEUR	Not available	£0,00
# 27	626-14373-10-00 626143731000 626143731000	.COUVERCLE DE PLONGEUR COUVERCLE DE PLONGEUR	Not available	£0,00
# 28	367-14375-01-00 367143750100 367143750100	.LEVIER, STARTER LEVIER, STARTER	Not available	£0,00
# 29	367-14377-00-00 367143770000 367143770000	.BUTEE BUTEE	Not available	£0,00
# 30	367-14325-00-00 985170401200 367143250000	SCREW, PAN HEAD	£0,48
# 31	97311-06025-00 970170602500 973110602500	BOLT, HEXAGON	£1,10
# 32	4U1-14396-00-00 367143960000 4U1143960000	PIPE, OVER FLOW	£3,01
# 33	5N6-14349-00-00 5N6143490000 5N6143490000	.DURITE DURITE	Not available	£0,00

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the CARBURETOR of your Yamaha DT50MX of 1986. Let us know if you have any questions.
