FENDER

SIDE COVER FOR YAMAHA WRF 450 2018

SWINGARM

(1) 1SL-21710-00

SIDE COVER ASSY 1

(2) 90387-08057

COLLAR (5V7)

(3) 5TA-21749-00

COLLAR

(4) 1SL-2176M-00

HOOK

(5) 977074001200

SCREW, TRUSS TAP.

(6) 90105-08230

BOLT, FLANGE

(7) 901190606300

BOLT, WITH WASHER (10V)

(8) 2GB-21720-10

SIDE COVER ASSY 2

(9) 90387-08057

COLLAR (5V7)

(10) 5BE-21749-00

COLLAR

(11) 5TA-21749-00

COLLAR

(12) 1SL-21719-00

GROMMET

(12) 1SL-21719-00

GROMMET

(13) 1DX-21746-01

DAMPER

(13) 1DX-21746-01

DAMPER

(14) 90105-08230

BOLT, FLANGE

(15) 901190606300

BOLT, WITH WASHER (10V)

(16) 2GC-217R0-80

SIDE COVER INSERT ASSY. 3

(16) B91-21730-00

SIDE COVER ASSY 3

(17) 17D-21749-00

COLLAR

(18) 90387-11009

COLLAR

(19) 90387-06372

COLLAR

(20) 1SL-21748-00

COLLAR

(21) 904801006800

GROMMET (397)

(22) 2GC-217S0-80

SIDE COVER INSERT ASSY. 4

(22) B91-21740-00

SIDE COVER ASSY 4

(23) 17D-21749-00

COLLAR

(24) 90387-11009

COLLAR

(25) 90387-06372

COLLAR

(26) 1SL-21748-00

COLLAR

(27) 904801006800

GROMMET (397)

(28) 90105-06064

BOLT, FLANGE

(28) 90105-06064

BOLT, FLANGE

(28) 90105-06064

BOLT, FLANGE

(28) 90105-06064

BOLT, FLANGE

(29) 90105-06179

BOLT, FLANGE

(29) 90105-06179

BOLT, FLANGE

(30) 90105-06203

BOLT, FLANGE

(30) 90105-06203

BOLT, FLANGE

(31) 1SL-2172A-00

PANEL 1

(32) 1SL-2172F-00

PANEL 2

	Part number	Description	Qty
# 1	1SL-21710-00 1SL2171000 1SL2171000	SIDE COVER ASSY 1	£84,43
# 2	90387-08057 9038708057 9038708057	COLLAR (5V7)	£3,01
# 3	5TA-21749-00 5TA2174900 5TA2174900	COLLAR	£5,58
# 4	1SL-2176M-00 1SL2176M00 1SL2176M00	HOOK	£4,32
# 5	97702-40012 977074001200 9770240012	SCREW, TRUSS TAP.	£0,48
# 6	90105-08230 9010508230 9010508230	BOLT, FLANGE	£2,18
# 7	90119-06096 901190606300 9011906096	BOLT, WITH WASHER (10V)	£2,09
# 8	2GB-21720-10 2GB2172010 2GB2172010	SIDE COVER ASSY 2	£87,24
# 9	90387-08057 9038708057 9038708057	COLLAR (5V7)	£3,01
# 10	5BE-21749-00 5BE2174900 5BE2174900	COLLAR	£3,52
# 11	5TA-21749-00 5TA2174900 5TA2174900	COLLAR	£5,58
# 12	1SL-21719-00 1SL2171900 1SL2171900	GROMMET	£9,71
# 13	1DX-21746-01 1DX2174601 1DX2174601	DAMPER	£15,26
# 14	90105-08230 9010508230 9010508230	BOLT, FLANGE	£2,18
# 15	90119-06096 901190606300 9011906096	BOLT, WITH WASHER (10V)	£2,09
# 16	2GC-217R0-80 2GC217R080 2GC217R080	SIDE COVER INSERT ASSY. 3	£219,46
# 16	B91-21730-00 B912173000 B912173000	SIDE COVER ASSY 3	£92,26
# 17	17D-21749-00 17D2174900 17D2174900	COLLAR	£10,13
# 18	90387-11009 9038711009 9038711009	COLLAR	£4,58
# 19	90387-06372 9038706372 9038706372	COLLAR	£1,18
# 20	1SL-21748-00 1SL2174800 1SL2174800	COLLAR	£7,73
# 21	904801006800 904801006800 904801006800	GROMMET (397)	£2,90
# 22	2GC-217S0-80 2GC217S080 2GC217S080	SIDE COVER INSERT ASSY. 4	£219,46
# 22	B91-21740-00 B912174000 B912174000	SIDE COVER ASSY 4	£92,26
# 23	17D-21749-00 17D2174900 17D2174900	COLLAR	£10,13
# 24	90387-11009 9038711009 9038711009	COLLAR	£4,58
# 25	90387-06372 9038706372 9038706372	COLLAR	£1,18
# 26	1SL-21748-00 1SL2174800 1SL2174800	COLLAR	£7,73
# 27	904801006800 904801006800 904801006800	GROMMET (397)	£2,90
# 28	90105-06064 9010506064 9010506064	BOLT, FLANGE	£0,52
# 29	90105-06179 9010506179 9010506179	BOLT, FLANGE	£1,91
# 30	90105-06203 9010506203 9010506203	BOLT, FLANGE	£1,39
# 31	1SL-2172A-00 1SL2172A00 1SL2172A00	PANEL 1	£15,68
# 32	1SL-2172F-00 1SL2172F00 1SL2172F00	PANEL 2	£15,68

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
