ELECTRICAL 1

ELECTRICAL 2 FOR YAMAHA XMAX 400 2013

(1) 5RU823100300

IGNITION COIL ASSY

(2) 5RU-82370-00

PLUG CAP ASSY

(3) 90465-10098

CLAMP

(4) 5RU-82353-00

HOSE

(5) 90153-06034

SCREW (5G3)

(6) 5PS-85790-00

THERMOSENSOR ASSY

(7) 90430-12X01

OIL SEAL(1HV)

(8) 5PS-82380-00

SENSOR, PRESSURE

(9) 5RU-8592A-00

SENSOR

(10) 90462-12007

CLAMP

(11) 90464-11004

CLAMP

(12) 1SD-H2590-00

WIRE HARNESS ASSY

(13) 5JJ-82151-20

FUSE

(14) 67F821514000

FUSE (10A)

(15) 1SD-H5700-00

THERMISTOR ASSY

(16) 1SD-H2509-00

WIRE, SUB LEAD

(17) 1B9-H2589-00

PROTECTER, WIRE HA

(18) 4KH-H3936-01

BAND,SWITCH CORD

(19) 90464-10008

CLAMP

(20) 90464-24230

CLAMP(4NK)

(21) 32SH25661100

SW SIDE STAND

(22) 90110-05X08

BOLT, HEXAGON SOCKET HEAD

(23) 956170510000

NUT, U

(24) 52S-H3371-00

HORN

(25) 9580M-06012

BOLT, FLANGE

(26) 3GD-81950-01

RELAY ASSY (3GD-01)

(27) 5EA-81950-20

RELAY ASSY (5EA-02)

(28) 5EA-81952-00

HOLDER,RELAY

(29) 1SD-H1952-10

HOLDER, RELAY

(30) 90109-06259

BOLT

(31) 3XV833502200

FLASHER RELAY ASSY

	Part number	Description	Qty
# 1	5RU-82310-00 5RU823100300 5RU8231000	IGNITION COIL ASSY	£65,18
# 2	5RU-82370-00 5RU8237000 5RU8237000	PLUG CAP ASSY	£56,40
# 3	90465-10098 9046510098 9046510098	CLAMP	£0,48
# 4	5RU-82353-00 5RU8235300 5RU8235300	HOSE	£5,10
# 5	90153-06034 9015306034 9015306034	SCREW (5G3)	£3,52
# 6	5PS-85790-00 5PS8579000 5PS8579000	THERMOSENSOR ASSY	£65,15
# 7	90430-12X01 9043012X01 9043012X01	OIL SEAL(1HV)	£2,08
# 8	5PS-82380-00 5PS8238000 5PS8238000	SENSOR, PRESSURE	£223,22
# 9	5RU-8592A-00 5RU8592A00 5RU8592A00	SENSOR	£267,14
# 10	90462-12007 9046212007 9046212007	CLAMP	£8,98
# 11	90464-11004 9046411004 9046411004	CLAMP	£3,76
# 12	1SD-H2590-00 1SDH259000 1SDH259000	WIRE HARNESS ASSY	£905,77
# 13	5JJ-82151-20 5JJ8215120 5JJ8215120	FUSE	£3,61
# 14	5JJ-82151-30 67F821514000 5JJ8215130	FUSE (10A)	£7,45
# 15	1SD-H5700-00 1SDH570000 1SDH570000	THERMISTOR ASSY	£29,06
# 16	1SD-H2509-00 1SDH250900 1SDH250900	WIRE, SUB LEAD	£93,47
# 17	1B9-H2589-00 1B9H258900 1B9H258900	PROTECTER, WIRE HA	£0,31
# 18	4KH-H3936-01 4KHH393601 4KHH393601	BAND, SWITCH CORD	£1,56
# 19	90464-10008 9046410008 9046410008	CLAMP	£1,96
# 20	90464-24230 9046424230 9046424230	CLAMP(4NK)	£2,90
# 21	32S-H2566-10 32SH25661100 32SH256610	SW SIDE STAND	£24,58
# 22	90110-05X08 9011005X08 9011005X08	BOLT, HEXAGON SOCKET HEAD	£1,18
# 23	95607-05100 956170510000 9560705100	NUT, U	£2,90
# 24	52S-H3371-00 52SH337100 52SH337100	HORN	£28,12
# 25	9580M-06012 9580M06012 9580M06012	BOLT, FLANGE	£2,90
# 26	3GD-81950-01 3GD8195001 3GD8195001	RELAY ASSY (3GD-01)	£80,90
# 27	5EA-81950-20 5EA8195020 5EA8195020	RELAY ASSY (5EA-02)	£80,90
# 28	5EA-81952-00 5EA8195200 5EA8195200	HOLDER, RELAY	£4,75
# 29	1SD-H1952-10 1SDH195210 1SDH195210	HOLDER, RELAY	£18,42
# 30	90109-06259 9010906259 9010906259	BOLT	£2,57
# 31	3XV-83350-21 3XV833502200 3XV8335021	FLASHER RELAY ASSY	£81,50

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the ELECTRICAL 2 of your Yamaha XMAX 400 of 2013. Let us know if you have any questions.
