CYLINDER

CRANKSHAFT / PISTON FOR YAMAHA OVATION LE 1990

AIR SHROUD & FAN

Item numbers

PISTON (STD)

85L116310096 85L116310096

Not available

PISTON (0.25MM O/S)

85L116350000 85L116350000

Not available

PISTON (0.50MM O/S)

85L116360000 85L116360000

Not available

PISTON RING SET (STD)

8G8116010000 8G8116010000

£51,77

Unit Price Incl. Tax

PISTON RING SET (1ST O/S)

8G8116011000 8G8116011000

Not available

PISTON RING SET (2ND O/S)

8G8116012000 8G8116012000

Not available

PIN, PISTON

137116330000

137116331000

£29,35

Unit Price Incl. Tax

CIRCLIP (137-11634-00)

934501702500 934501702500

£2,00

Unit Price Incl. Tax

BRG, CYL-CAL ROLLER 14-7G KY

93310216E100 93310216E100

£15,50

Unit Price Incl. Tax

CRANKSHAFT ASSY

85L114000000 85L114000000

Not available

.CRANK 1

8G8114120100 8G8114120100

Not available

.CRANK 2

8L3114220100 8L3114220100

Not available

CRANK 3

8L3114320100 8L3114320100

Not available

CRANK 4

8G8114420100 8G8114420100

Not available

KEY, WOOD RUFF (324)

902800501400 902800501400

£3,79

Unit Price Incl. Tax

PIN, CRANK

8G8116810000 8G8116810000

£37,27

Unit Price Incl. Tax

WASHER (29L)

902092224800 902092224800

£6,73

Unit Price Incl. Tax

ROD, CONNECTING

2R8116510000

34X116510000

£44,04

Unit Price Incl. Tax

BEARING, CYLIMDRICAL (4A7)

93310422L000 93310422L000

£17,71

Unit Price Incl. Tax

BRG, R-B 6306 72MM 354G KY

933063061800 933063061800

Not available

BEARING (8G8)

933062062000

933062061700

£73,39

Unit Price Incl. Tax

BEARING

933063052100

933063057100

£68,48

Unit Price Incl. Tax

.SEAL, LABYRINTH 1

8L3115150000 8L3115150000

Not available

PIN, SPRING (663)

916093001000

916903001000

£2,54

Unit Price Incl. Tax

.COLLAR

82Y114780000 82Y114780000

Not available

.OIL SEAL

931024037300 931024037300

Not available

.GEAR, PUMP DRIVE

85L131780000 85L131780000

Not available

CIRCLIP (1J7)

934407204900 934407204900

£7,74

Unit Price Incl. Tax

OIL SEAL (8G8)

931022518300 931022518300

£13,10

Unit Price Incl. Tax

KEY, WOODRUFF

902800501300

902800500100

£8,38

Unit Price Incl. Tax

NUT

901701618200

901701642500

£3,12

Unit Price Incl. Tax

WASHER(JN5)

929011610000

929071610000

£9,04

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
