ELECTRICAL 1

ELECTRICAL 2 FOR YAMAHA YZ 250 F 2019

ALTERNATIVE CHASSIS

(1) B7B-81960-00

RECTIFIER & REGULATOR ASSY

(2) B7B-21287-00

BRACKET, REGULATOR

(3) 90105-06219

BOLT, FLANGE

(4) 90480-13025

GROMMET

(5) 903870757300

COLLAR (8H6)

(6) 90105-06064

BOLT, FLANGE

(7) B7B825901000

WIRE HARNESS ASSY

(7) B7B825901000

WIRE HARNESS ASSY

(8) 4WA-81980-00

DIODE ASSY

(9) 3WP-81980-00

DIODE ASSY

(10) 1SL-82309-00

WIRE, SUB LEAD

(11) 33D-82378-00

CONNECTOR

(12) B7B-82388-00

PLATE

(13) 90105-06110

BOLT, FLANGE

(14) 95022-06010

BOLT, FLANGE

(15) 90464-17003

CLAMP

(16) 904641519500

CLAMP(4FM)

(17) 904641519500

CLAMP(4FM)

(18) 1UA-82591-00

BAND

(19) BR9-82100-39

BATTERY ASSY (BR98)

(20) BR9-82128-00

BRACKET, BATTERY

(21) 90201-06088

WASHER, PLATE

(22) 90119-06133

BOLT, WITH WASHER

(22) 90119-06133

BOLT, WITH WASHER

(23) BR9-82176-00

DAMPER

(24) 8CY-82131-00

BAND, BATTERY

(25) BR9-82115-00

WIRE, PLUS LEAD

(26) BR9-82116-00

WIRE, MINUS LEAD

(27) 90105-06064

BOLT, FLANGE

(28) 2GB-81940-00

STARTER RELAY ASSY (RC19-102B)

(29) 36Y-82151-00

FUSE (12V 15A)

(30) 5SL-82119-10

COVER, LEAD WIRE

(31) 95022-06008

BOLT, FLANGE

(32) 1ST-81950-00

RELAY ASSY (1ST-00)

(33) 5JJ-81952-00

HOLDER, RELAY

(34) 90465-10098

CLAMP

	Part number	Description	Qty
# 1	B7B-81960-00 B7B8196000 B7B8196000	RECTIFIER & REGULATOR ASSY	£153,08
# 2	B7B-21287-00 B7B2128700 B7B2128700	BRACKET, REGULATOR	£12,48
# 3	90105-06219 9010506219 9010506219	BOLT, FLANGE	£1,04
# 4	90480-13025 9048013025 9048013025	GROMMET	£3,25
# 5	90387-066J9 903870757300 90387066J9	COLLAR (8H6)	£1,32
# 6	90105-06064 9010506064 9010506064	BOLT, FLANGE	£0,52
# 7	B7B-82590-00 B7B825901000 B7B8259000	WIRE HARNESS ASSY	£537,01
# 8	4WA-81980-00 4WA8198000 4WA8198000	DIODE ASSY	£17,06
# 9	3WP-81980-00 3WP8198000 3WP8198000	DIODE ASSY	£13,73
# 10	1SL-82309-00 1SL8230900 1SL8230900	WIRE, SUB LEAD	£23,42
# 11	33D-82378-00 33D8237800 33D8237800	CONNECTOR	£3,11
# 12	B7B-82388-00 B7B8238800 B7B8238800	PLATE	£8,32
# 13	90105-06110 9010506110 9010506110	BOLT, FLANGE	£0,38
# 14	95022-06010 9502206010 9502206010	BOLT, FLANGE	£0,28
# 15	90464-17003 9046417003 9046417003	CLAMP	£1,86
# 16	90464-13077 904641519500 9046413077	CLAMP(4FM)	£2,09
# 17	90464-13073 904641519500 9046413073	CLAMP(4FM)	£2,09
# 18	1UA-82591-00 1UA8259100 1UA8259100	BAND	£1,58
# 19	BR9-82100-39 BR98210039 BR98210039	BATTERY ASSY (BR98)	Not available	£0,00
# 20	BR9-82128-00 BR98212800 BR98212800	BRACKET, BATTERY	£54,56
# 21	90201-06088 9020106088 9020106088	WASHER, PLATE	£0,38
# 22	90119-06133 9011906133 9011906133	BOLT, WITH WASHER	£0,66
# 23	BR9-82176-00 BR98217600 BR98217600	DAMPER	£3,42
# 24	8CY-82131-00 8CY8213100 8CY8213100	BAND, BATTERY	£10,64
# 25	BR9-82115-00 BR98211500 BR98211500	WIRE, PLUS LEAD	£19,15
# 26	BR9-82116-00 BR98211600 BR98211600	WIRE, MINUS LEAD	£19,31
# 27	90105-06064 9010506064 9010506064	BOLT, FLANGE	£0,52
# 28	2GB-81940-00 2GB8194000 2GB8194000	STARTER RELAY ASSY (RC19-102B)	£44,63
# 29	36Y-82151-00 36Y8215100 36Y8215100	FUSE (12V 15A)	£3,68
# 30	5SL-82119-10 5SL8211910 5SL8211910	COVER, LEAD WIRE	£4,72
# 31	95022-06008 9502206008 9502206008	BOLT, FLANGE	£0,38
# 32	1ST-81950-00 1ST8195000 1ST8195000	RELAY ASSY (1ST-00)	£12,41
# 33	5JJ-81952-00 5JJ8195200 5JJ8195200	HOLDER, RELAY	£6,11
# 34	90465-10098 9046510098 9046510098	CLAMP	£0,48
