CRANKCASE FOR YAMAHA YZ250F 2012

COVER - ENGINE 1

Item numbers

CRANKCASE ASSY

5XC1510038YX 5XC1510038YX

£826,42

Unit Price Incl. Tax

PIN, DOWEL(4XL)

936121625400 936121625400

£4,94

Unit Price Incl. Tax

BOLT

913120604500 913120604500

Not available

BOLT, HEXAGON SOCKET HEAD(M01)

913120605500

9011006X7500

£1,72

Unit Price Incl. Tax

BOLT

913120607000 913120607000

£1,69

Unit Price Incl. Tax

BOLT, FLANGE

950221001600 950221001600

£1,69

Unit Price Incl. Tax

GASKET (5R6)

904301018800

904301017100

£3,89

Unit Price Incl. Tax

HOLDER, CLUTCH CABLE

5NL154410100 5NL154410100

£16,92

Unit Price Incl. Tax

COVER, CRANKCASE 2

17D154219000 17D154219000

£44,54

Unit Price Incl. Tax

BOLT, FLANGE

901050618900 901050618900

£0,89

Unit Price Incl. Tax

GUIDE, CHAIN

5NL174660000 5NL174660000

£27,01

Unit Price Incl. Tax

PLATE, BEARING COVER

5BE153830100 5BE153830100

£7,85

Unit Price Incl. Tax

SCREW, COUNTERSUNK

901510607100 901510607100

£3,94

Unit Price Incl. Tax

PLATE, BEARING COVER

5NL153880000 5NL153880000

£6,62

Unit Price Incl. Tax

BOLT, FLANGE

901050608100

950220601200

£0,43

Unit Price Incl. Tax

PLATE, BEARING COVER

4JT153810100 4JT153810100

£12,79

Unit Price Incl. Tax

SCREW, COUNTERSUNK

901490607400

901510605200

£1,02

Unit Price Incl. Tax

PLATE, STOPPER 2

5DH185620000 5DH185620000

£2,35

Unit Price Incl. Tax

BOLT, FLANGE

901050608100

950220601200

£0,43

Unit Price Incl. Tax

O-RING (371)

932101019700 932101019700

£1,85

Unit Price Incl. Tax

PIN, DOWEL(3VD)

995301011400 995301011400

£2,54

Unit Price Incl. Tax

COLLAR

903871800700 903871800700

£23,47

Unit Price Incl. Tax

PIN, DOWEL(2VG)

995301011600 995301011600

£1,14

Unit Price Incl. Tax

CLAMP

904651001300 904651001300

£16,87

Unit Price Incl. Tax
