CRANKCASE

COVER - ENGINE 1 FOR YAMAHA YBR250 2009

STARTER CLUTCH

(1) 1S4-E5411-01-35

COVER, CRANKCASE 1

(2) 903403212300

PLUG, STRAIGHT SCREW(3AW)

(3) 932103217200

O-RING (341)

(4) 9034014W0600

PLUG, STRAIGHT SCREW

(5) 932101436900

O-RING (2H9)

(6) BC5E54510000

GASKET, CRANKCASE

(7) 99530-10114

PIN, DOWEL(3VD)

(8) 95024-06040

BOLT, FLANGE(4KM)

(9) 95024-06030

BOLT, FLANGE(4AS)

(10) 95024-06050

BOLT, SMALL FLANGE

(11) 90465-20801

CLAMP

(12) 9131M-05012

BOLT, HEXAGON SOCK

(13) 1S4-E5113-00

PLATE

(14) 1S4-E5418-00-35

COVER, CHAIN CASE

(15) 95024-06016

BOLT, FLANGE(2UJ)

(16) 1S4E54210135

COVER, CRANKCASE 2

(17) BC5E54610000

GASKET, CRANKCASE COVER 2

(18) 99530-10114

PIN, DOWEL(3VD)

(19) 95024-06025

BOLT, FLANGE(4KG)

(20) 95024-06035

BOLT, FLANGE(4BH)

(21) 95024-06050

BOLT, SMALL FLANGE

(22) 95024-06055

BOLT, FLANGE(4EB)

(23) 904300601400

GASKET 256113960000

(24) 5HH-E5362-00

PLUG, OIL LEVEL

(25) 932101912300

O-RING (646)

(26) 1S4-E5415-00

COVER, GENERATOR

(27) 95024-06016

BOLT, FLANGE(2UJ)

(28) 93210-74800

O-RING

	Part number	Description	Qty
# 1	1S4-E5411-01-35 1S4E54110135 1S4E54110135	COVER, CRANKCASE 1	Not available	£0,00
# 2	90340-32W03 903403212300 9034032W03	PLUG, STRAIGHT SCREW(3AW)	£8,83
# 3	93210-32800 932103217200 9321032800	O-RING (341)	£3,98
# 4	90340-14W02 9034014W0600 9034014W02	PLUG, STRAIGHT SCREW	£7,28
# 5	93210-14800 932101436900 9321014800	O-RING (2H9)	£0,86
# 6	1S4-E5451-00 1S4E545100	GASKET, CRANKCASE	Not available	£0,00
# 7	99530-10114 9953010114 9953010114	PIN, DOWEL(3VD)	£2,35
# 8	95024-06040 9502406040 9502406040	BOLT, FLANGE(4KM)	£1,20
# 9	95024-06030 9502406030 9502406030	BOLT, FLANGE(4AS)	£1,18
# 10	95024-06050 9502406050 9502406050	BOLT, SMALL FLANGE	£1,20
# 11	90465-20801 9046520801 9046520801	CLAMP	£5,23
# 12	9131M-05012 9131M05012 9131M05012	BOLT, HEXAGON SOCK	£0,31
# 13	1S4-E5113-00 1S4E511300 1S4E511300	PLATE	Not available	£0,00
# 14	1S4-E5418-00-35 1S4E54180035 1S4E54180035	COVER, CHAIN CASE	Not available	£0,00
# 15	95024-06016 9502406016 9502406016	BOLT, FLANGE(2UJ)	£2,35
# 16	1S4-E5421-00-35 1S4E54210035	COVER, CRANKCASE 2	Not available	£0,00
# 17	1S4-E5461-00 1S4E546100	GASKET, CRANKCASE COVER 2	Not available	£0,00
# 18	99530-10114 9953010114 9953010114	PIN, DOWEL(3VD)	£2,35
# 19	95024-06025 9502406025 9502406025	BOLT, FLANGE(4KG)	£1,56
# 20	95024-06035 9502406035 9502406035	BOLT, FLANGE(4BH)	£1,37
# 21	95024-06050 9502406050 9502406050	BOLT, SMALL FLANGE	£1,20
# 22	95024-06055 9502406055 9502406055	BOLT, FLANGE(4EB)	£1,69
# 23	90430-06817 9043006817	GASKET 256113960000	Not available	£0,00
# 24	5HH-E5362-00 5HHE536200 5HHE536200	PLUG, OIL LEVEL	£5,02
# 25	93210-19800 932101912300 9321019800	O-RING (646)	£3,64
# 26	1S4-E5415-00 1S4E541500 1S4E541500	COVER, GENERATOR	Not available	£0,00
# 27	95024-06016 9502406016 9502406016	BOLT, FLANGE(2UJ)	£2,35
# 28	93210-74800 9321074800 9321074800	O-RING	Not available	£0,00
