STEERING

FRONT FORK FOR YAMAHA WR250F 2009

FUEL TANK

(1) 5UM23102F200

FRONT FORK ASSY (L.H)

(2) 5TJ-23136-C0

TUBE, OUTER (RIGHT)

(3) 5TJ23120C100

INNER TUBE COMP.2

(4) 5XE-23171-L0

PISTON, FRONT FORK

(5) 5XE-23125-L0

METAL, SLIDE 1

(6) 5XE-23146-L0

WASHER, OIL SEAL

(7) 1C3-23145-L0

OIL SEAL

(8) 5XE-23153-L0

RING, SNAP

(9) 5XE-23144-L0

SEAL, DUST

(10) 5UM-23170-E0

CYLINDER COMP., FRONT FORK

(11) 5XE-23142-L0

SEAT, SPRING UPPER

(12) 5XE-23393-L0

NUT, SPECIAL

(13) 5UM-2316A-F0

VALVE COMP.

(14) 5NY-23188-L0

O-RING

(15) 5NY-23147-L0

O-RING

(16) 4SS-23158-L0

GASKET

(17) 5TJ231414000

SPRING, FRONT FORK

(18) 5XE-23111-L0

BOLT, CAP

(19) 5XE-23117-L0

GUIDE, SPRING

(20) 1C3-2314F-M0

PROTECTER GUIDE COMP., 1

(21) 3JD-2312G-L0

PLUG

(22) 5UM23103F200

FRONT FORK ASSY (R.H)

(23) 5TJ-23136-C0

TUBE, OUTER (RIGHT)

(24) 5TJ23110C100

INNER TUBE COMP.1

(25) 5XE-23171-L0

PISTON, FRONT FORK

(26) 5XE-23125-L0

METAL, SLIDE 1

(27) 5XE-23146-L0

WASHER, OIL SEAL

(28) 1C3-23145-L0

OIL SEAL

(29) 5XE-23153-L0

RING, SNAP

(30) 5XE-23144-L0

SEAL, DUST

(31) 5UM-23170-E0

CYLINDER COMP., FRONT FORK

(32) 5XE-23142-L0

SEAT, SPRING UPPER

(33) 5XE-23393-L0

NUT, SPECIAL

(34) 5UM-2316A-F0

VALVE COMP.

(35) 5NY-23188-L0

O-RING

(36) 5NY-23147-L0

O-RING

(37) 4SS-23158-L0

GASKET

(38) 5TJ231414000

SPRING, FRONT FORK

(39) 5XE-23111-L0

BOLT, CAP

(40) 5XE-23117-L0

GUIDE, SPRING

(41) 1C3-2314F-M0

PROTECTER GUIDE COMP., 1

(42) 3JD-2312G-L0

PLUG

(43) 5UM-23340-L0

UNDER BRACKET COMP.

(44) 90105-08134

BOLT, FLANGE

(44) 90105-08134

BOLT, FLANGE

(44) 90105-08134

BOLT, FLANGE

(44) 90105-08134

BOLT, FLANGE

(45) 5TJ-23525-C0

GUIDE

(46) 5TJ-2315J-C0

PROTECTOR 2

(47) 4XL2153A1100

EMBLEM, YAMAHA

(48) 1C3-2315H-10

PROTECTOR 1

(49) 4XL2153A1100

EMBLEM, YAMAHA

(50) 3SP-23356-L0

BOLT 2

(50) 3SP-23356-L0

BOLT 2

(51) 5XC-23466-L0

CLAMP

(52) 5XC-23467-L0

CLAMP

(53) 957800650000

NUT, FLANGE(7NB)

	Part number	Description	Qty
# 1	5UM-23102-F0 5UM23102F200 5UM23102F0	FRONT FORK ASSY (L.H)	£2 077,96
# 2	5TJ-23136-C0 5TJ23136C0 5TJ23136C0	TUBE, OUTER (RIGHT)	£49,44
# 3	5TJ-23120-C0 5TJ23120C100 5TJ23120C0	INNER TUBE COMP.2	£424,02
# 4	5XE-23171-L0 5XE23171L0 5XE23171L0	PISTON, FRONT FORK	£17,18
# 5	5XE-23125-L0 5XE23125L0 5XE23125L0	METAL, SLIDE 1	£17,98
# 6	5XE-23146-L0 5XE23146L0 5XE23146L0	WASHER, OIL SEAL	£9,30
# 7	1C3-23145-L0 1C323145L0 1C323145L0	OIL SEAL	£21,36
# 8	5XE-23153-L0 5XE23153L0 5XE23153L0	RING, SNAP	£2,23
# 9	5XE-23144-L0 5XE23144L0 5XE23144L0	SEAL, DUST	£16,44
# 10	5UM-23170-E0 5UM23170E0 5UM23170E0	CYLINDER COMP., FRONT FORK	£727,42
# 11	5XE-23142-L0 5XE23142L0 5XE23142L0	SEAT, SPRING UPPER	£22,66
# 12	5XE-23393-L0 5XE23393L0 5XE23393L0	NUT, SPECIAL	£25,03
# 13	5UM-2316A-F0 5UM2316AF0 5UM2316AF0	VALVE COMP.	£378,41
# 14	5NY-23188-L0 5NY23188L0 5NY23188L0	O-RING	£5,41
# 15	5NY-23147-L0 5NY23147L0 5NY23147L0	O-RING	£5,84
# 16	4SS-23158-L0 4SS23158L0 4SS23158L0	GASKET	£3,90
# 17	5TJ-23141-A0 5TJ231414000 5TJ23141A0	SPRING, FRONT FORK	£119,36
# 18	5XE-23111-L0 5XE23111L0 5XE23111L0	BOLT, CAP	£280,99
# 19	5XE-23117-L0 5XE23117L0 5XE23117L0	GUIDE, SPRING	£2,50
# 20	1C3-2314F-M0 1C32314FM0 1C32314FM0	PROTECTER GUIDE COMP., 1	£37,15
# 21	3JD-2312G-L0 3JD2312GL0 3JD2312GL0	PLUG	£5,50
# 22	5UM-23103-F0 5UM23103F200 5UM23103F0	FRONT FORK ASSY (R.H)	£2 077,96
# 23	5TJ-23136-C0 5TJ23136C0 5TJ23136C0	TUBE, OUTER (RIGHT)	£49,44
# 24	5TJ-23110-C0 5TJ23110C100 5TJ23110C0	INNER TUBE COMP.1	£424,02
# 25	5XE-23171-L0 5XE23171L0 5XE23171L0	PISTON, FRONT FORK	£17,18
# 26	5XE-23125-L0 5XE23125L0 5XE23125L0	METAL, SLIDE 1	£17,98
# 27	5XE-23146-L0 5XE23146L0 5XE23146L0	WASHER, OIL SEAL	£9,30
# 28	1C3-23145-L0 1C323145L0 1C323145L0	OIL SEAL	£21,36
# 29	5XE-23153-L0 5XE23153L0 5XE23153L0	RING, SNAP	£2,23
# 30	5XE-23144-L0 5XE23144L0 5XE23144L0	SEAL, DUST	£16,44
# 31	5UM-23170-E0 5UM23170E0 5UM23170E0	CYLINDER COMP., FRONT FORK	£727,42
# 32	5XE-23142-L0 5XE23142L0 5XE23142L0	SEAT, SPRING UPPER	£22,66
# 33	5XE-23393-L0 5XE23393L0 5XE23393L0	NUT, SPECIAL	£25,03
# 34	5UM-2316A-F0 5UM2316AF0 5UM2316AF0	VALVE COMP.	£378,41
# 35	5NY-23188-L0 5NY23188L0 5NY23188L0	O-RING	£5,41
# 36	5NY-23147-L0 5NY23147L0 5NY23147L0	O-RING	£5,84
# 37	4SS-23158-L0 4SS23158L0 4SS23158L0	GASKET	£3,90
# 38	5TJ-23141-A0 5TJ231414000 5TJ23141A0	SPRING, FRONT FORK	£119,36
# 39	5XE-23111-L0 5XE23111L0 5XE23111L0	BOLT, CAP	£280,99
# 40	5XE-23117-L0 5XE23117L0 5XE23117L0	GUIDE, SPRING	£2,50
# 41	1C3-2314F-M0 1C32314FM0 1C32314FM0	PROTECTER GUIDE COMP., 1	£37,15
# 42	3JD-2312G-L0 3JD2312GL0 3JD2312GL0	PLUG	£5,50
# 43	5UM-23340-L0 5UM23340L0 5UM23340L0	UNDER BRACKET COMP.	£714,04
# 44	90105-08134 9010508134 9010508134	BOLT, FLANGE	£1,58
# 45	5TJ-23525-C0 5TJ23525C0 5TJ23525C0	GUIDE	£19,80
# 46	5TJ-2315J-C0 5TJ2315JC0 5TJ2315JC0	PROTECTOR 2	£50,00
# 47	4XL-2153A-10 4XL2153A1100 4XL2153A10	EMBLEM, YAMAHA	£38,62
# 48	1C3-2315H-10 1C32315H10 1C32315H10	PROTECTOR 1	£24,89
# 49	4XL-2153A-10 4XL2153A1100 4XL2153A10	EMBLEM, YAMAHA	£38,62
# 50	3SP-23356-L0 3SP23356L0 3SP23356L0	BOLT 2	£1,32
# 51	5XC-23466-L0 5XC23466L0 5XC23466L0	CLAMP	£6,14
# 52	5XC-23467-L0 5XC23467L0 5XC23467L0	CLAMP	£6,14
# 53	95702-06500 957800650000 9570206500	NUT, FLANGE(7NB)	£1,55

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
