SIDE COVER

SWINGARM FOR YAMAHA TT250R 2009

REAR SHOCK ABSORBER

Item numbers

REAR ARM COMP.

4PX221100100 4PX221100100

Not available

END 3

4GY221770000 4GY221770000

Not available

BRACKET

4GY221650000 4GY221650000

Not available

SCREW, PAN HEAD(3LA)

985070501000

985170501000

£0,49

Unit Price Incl. Tax

BEARING, CYLINDRICAL(4PT)

933152225100 933152225100

£38,05

Unit Price Incl. Tax

WASHER, PLATE(30X)

90201254H800 90201254H800

£3,42

Unit Price Incl. Tax

OIL SEAL (35X41.5X8-483)

931083500400 931083500400

£6,91

Unit Price Incl. Tax

COVER

30X2219X0000 30X2219X0000

£9,17

Unit Price Incl. Tax

BUSH

29L221840000 29L221840000

£15,02

Unit Price Incl. Tax

SEAL, GUARD

4GY221510000 4GY221510000

Not available

BOLT, HEXAGON

970070602000

970170602000

£1,49

Unit Price Incl. Tax

WASHER, PLATE (4X4)

90201067A000 90201067A000

£3,12

Unit Price Incl. Tax

DAMPER

22F2139X0000 22F2139X0000

£1,37

Unit Price Incl. Tax

SUPPORT, CHAIN

3XP221990300 3XP221990300

£23,81

Unit Price Incl. Tax

PROTECTOR, CHAIN

3JD221470000 3JD221470000

£61,10

Unit Price Incl. Tax

SCREW, FLAT HEAD(3XP)

987070605000 987070605000

£1,42

Unit Price Incl. Tax

COVER, THRUST 1

3JD221280000 3JD221280000

£63,40

Unit Price Incl. Tax

BOLT, FLANGE

901050660100

958170602500

£4,26

Unit Price Incl. Tax

NUT, FLANGE(4MV)

957070650000 957070650000

£4,21

Unit Price Incl. Tax

CASE, CHAIN

4PX223110000 4PX223110000

£39,58

Unit Price Incl. Tax

BOLT(8CP)

901190620500

970170601400

£1,21

Unit Price Incl. Tax

SHAFT, PIVOT

5X6221410100 5X6221410100

£40,40

Unit Price Incl. Tax

NUT, U (6TD)

901851612700

956171610000

£16,31

Unit Price Incl. Tax

WASHER, PLATE(33Y)

90201164H400 90201164H400

£3,42

Unit Price Incl. Tax

ARM, RELAY

4GY2217A0000 4GY2217A0000

£142,72

Unit Price Incl. Tax

BEARING, CYLINDRICAL(4RR)

933153205300 933153205300

£37,62

Unit Price Incl. Tax

OIL SEAL

931092007600 931092007600

£6,44

Unit Price Incl. Tax

COLLAR(2HG)

90387167R500 90387167R500

£25,10

Unit Price Incl. Tax

COLLAR(4RR)

903871606R00 903871606R00

£34,66

Unit Price Incl. Tax

COLLAR(1LV)

90387164N200 90387164N200

£26,41

Unit Price Incl. Tax

BOLT, FLANGE(3HP)

958171001600 958171001600

£3,12

Unit Price Incl. Tax

WASHER, PLATE (17K)

90201106F200 90201106F200

£2,44

Unit Price Incl. Tax

NUT(4RR)

901791066500 901791066500

£73,67

Unit Price Incl. Tax

BOLT, UNION(4RR)

904011416300 904011416300

£58,86

Unit Price Incl. Tax

WASHER, PLATE(33Y)

90201164H400 90201164H400

£3,42

Unit Price Incl. Tax

WASHER PLATE (3L6)

902011474000 902011474000

£2,16

Unit Price Incl. Tax

NUT, SELF-LOCKING

901851411200 901851411200

£10,10

Unit Price Incl. Tax

BEARING(3XP)

933999993500 933999993500

£69,49

Unit Price Incl. Tax

CIRCLIP (23X)

934403011300 934403011300

£0,49

Unit Price Incl. Tax

SEAL, DUST

3XJ224750000 3XJ224750000

£7,07

Unit Price Incl. Tax

COLLAR(3XJ)

90387103X900 90387103X900

£26,41

Unit Price Incl. Tax

ROD, CONNECTING 1

4GY2217F0000 4GY2217F0000

£201,49

Unit Price Incl. Tax

BEARING, CYLINDRICAL(4RR)

933153205200 933153205200

£35,82

Unit Price Incl. Tax

OIL SEAL

931092007600 931092007600

£6,44

Unit Price Incl. Tax

NUT

901791200100 901791200100

Not available

BOLT, FLANGE(4GY)

958171201600 958171201600

£3,22

Unit Price Incl. Tax

COVER

1HX2135F1000 1HX2135F1000

£8,04

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
