HULL & DECK 2

GUNWALE & MAT FOR YAMAHA FX HO 2024

VENTILATION

Item numbers

GUNWALE, BOW

F3XU25111100 F3XU25111100

£102,89

Unit Price Incl. Tax

BOLT, SPECIAL

F1WU491K0100 F1WU491K0100

£4,73

Unit Price Incl. Tax

NUT, LOCK

F2NU142L0000 F2NU142L0000

£1,14

Unit Price Incl. Tax

GUNWALE, SIDE

F3XU25121000 F3XU25121000

£67,94

Unit Price Incl. Tax

INNER, GUNWALE

F3XU2519B000 F3XU2519B000

£43,16

Unit Price Incl. Tax

RIVET, BLIND (AD610ABS/LLM10P)

90267489U800

902674893200

£1,13

Unit Price Incl. Tax

WASHER

9299R0520000 9299R0520000

£2,03

Unit Price Incl. Tax

JOINT, GUNWALE LH

F3XU252E1000 F3XU252E1000

£100,19

Unit Price Incl. Tax

GUNWALL INSIDE

F3XU2514N000 F3XU2514N000

£27,64

Unit Price Incl. Tax

BOLT, SPECIAL

F1WU491K0100 F1WU491K0100

£4,73

Unit Price Incl. Tax

SCREW

F3XU78231200

F3XU78231100

£2,17

Unit Price Incl. Tax

SCREW

F7KU81980000 F7KU81980000

£1,97

Unit Price Incl. Tax

BRACKET

F3XU49490000 F3XU49490000

£7,33

Unit Price Incl. Tax

RIVET, BLIND(FN8, USA)

90267489U600 90267489U600

£1,48

Unit Price Incl. Tax

NUT, LOCK

F2NU142L0000 F2NU142L0000

£1,14

Unit Price Incl. Tax

JOINT, GUNWALE RH

F3XU252F1000 F3XU252F1000

£100,19

Unit Price Incl. Tax

GUNWALL INSIDE

F3XU2514P000 F3XU2514P000

£27,64

Unit Price Incl. Tax

BOLT, SPECIAL

F1WU491K0100 F1WU491K0100

£4,73

Unit Price Incl. Tax

SCREW

F3XU78231200

F3XU78231100

£2,17

Unit Price Incl. Tax

SCREW

F7KU81980000 F7KU81980000

£1,97

Unit Price Incl. Tax

BRACKET

F3XU49490000 F3XU49490000

£7,33

Unit Price Incl. Tax

RIVET, BLIND(FN8, USA)

90267489U600 90267489U600

£1,48

Unit Price Incl. Tax

NUT, LOCK

F2NU142L0000 F2NU142L0000

£1,14

Unit Price Incl. Tax

GUNWALE, STERN 1

F3XU251D1000 F3XU251D1000

£84,17

Unit Price Incl. Tax

INNER GUNWALE, AFT

F3XU255CN000 F3XU255CN000

£21,32

Unit Price Incl. Tax

BOLT, SPECIAL

F1WU491K0100 F1WU491K0100

£4,73

Unit Price Incl. Tax

SCREW

F3XU78231200

F3XU78231100

£2,17

Unit Price Incl. Tax

NUT, LOCK

F2NU142L0000 F2NU142L0000

£1,14

Unit Price Incl. Tax

GUNWALE, STERN 2

F3XU251E1000 F3XU251E1000

£84,17

Unit Price Incl. Tax

INNER GUNWALE, AFT

F3XU255CP000 F3XU255CP000

£21,32

Unit Price Incl. Tax

BOLT, SPECIAL

F1WU491K0100 F1WU491K0100

£4,73

Unit Price Incl. Tax

SCREW

F3XU78231200

F3XU78231100

£2,17

Unit Price Incl. Tax

NUT, LOCK

F2NU142L0000 F2NU142L0000

£1,14

Unit Price Incl. Tax

COVER, GUNWALE 1

F3XU252C1100 F3XU252C1100

£28,93

Unit Price Incl. Tax

BOLT, SPECIAL

F1WU491K0100 F1WU491K0100

£4,73

Unit Price Incl. Tax

NUT, LOCK

F2NU142L0000 F2NU142L0000

£1,14

Unit Price Incl. Tax

MAT, UPPER

F3XU35810100 F3XU35810100

£101,27

Unit Price Incl. Tax

MAT, STEP 1

F3XU351H0000 F3XU351H0000

£61,63

Unit Price Incl. Tax

MAT, STEP 2

F3XU351J0000 F3XU351J0000

£61,63

Unit Price Incl. Tax

MAT, STEP 3

F3XU351K0000 F3XU351K0000

£82,70

Unit Price Incl. Tax

MAT, STEP 4

F3XU351M0000 F3XU351M0000

£82,70

Unit Price Incl. Tax

MAT, STEP 5

F3XU351N0000 F3XU351N0000

£93,66

Unit Price Incl. Tax

MAT, STEP 6

F3XU351P0000 F3XU351P0000

£93,66

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the GUNWALE & MAT of your Yamaha FX HO of 2024. Let us know if you have any questions.
