FUEL TANK

FUEL TANK 2 FOR YAMAHA XV1900A 2012

SEAT

(1) 1D7-2172E-00

STAY, SIDE COVER 1

(2) 95022-08055

BOLT, FLANGE

(3) 1D7-24280-00

TANK, FUEL

(4) 1D7-24185-00

DAMPER, LOCATING 5

(5) 903870614M00

COLLAR

(6) 95D320603000

BOLT, FLANGE DEEP RECESS

(7) 1D7-24305-00

FUEL PIPE JOINT COMP. 2

(7) 1D7-24305-00

FUEL PIPE JOINT COMP. 2

(8) 90464-20010

CLAMP

(8) 90464-20010

CLAMP

(9) 1D7-24311-00

PIPE, FUEL 1

(10) 1D7-24312-00

PIPE 2

(11) 1D7-24313-00

PIPE 3

(12) 1D7-24314-00

PIPE 4

(13) 5PX-2411M-00

CLIP

(13) 5PX-2411M-00

CLIP

(13) 5PX-2411M-00

CLIP

(13) 5PX-2411M-00

CLIP

(13) 5PX-2411M-00

CLIP

(13) 5PX-2411M-00

CLIP

(14) 90467-16009

CLIP

(14) 90467-16009

CLIP

(15) 1D7-2419F-00

BRACKET, CANISTOR

(16) 901190580500

BOLT, WITH WASHER

(17) 95302-05800

NUT, CROWN

(18) 1D7139070100

FUEL PUMP COMP.

(19) 5PX-24491-00

BRACKET, FUEL PUMP

(20) 90111-05026

BOLT,HEX. SOCKET BUTTON

(21) 5PX244861100

O-RING

(22) 5PX-24145-00

PLATE, DAMPER

(23) 1D7-13971-00

PIPE, FUEL 1

(24) 90464-15004

CLAMP

(25) 5PX-13973-01

PIPE, FUEL 3

(26) 904671313300

CLIP(3YX)

(26) 904671313300

CLIP(3YX)

(26) 904671313300

CLIP(3YX)

(26) 904671313300

CLIP(3YX)

(27) 1D7-14295-00

PIPE, FUEL

(28) 5PX-14435-00

GROMMET

(29) 5PX-14261-01

HOLDER

(30) 95027-06010

BOLT, FLANGE(4MY)

(31) 1D7-13974-00

PIPE, FUEL 4

(32) 1D7-24316-10

PIPE 6

(33) 90467-09002

CLIP

(33) 90467-09002

CLIP

(33) 90467-09002

CLIP

(33) 90467-09002

CLIP

(33) 90467-09002

CLIP

(33) 90467-09002

CLIP

(33) 90467-09002

CLIP

(33) 90467-09002

CLIP

(33) 90467-09002

CLIP

(33) 90467-09002

CLIP

(33) 90467-09002

CLIP

(34) 90413-06002

WAY 3

(35) 90413-06031

WAY 3

(36) 1D7-24317-10

PIPE 7

(37) 1D7-24321-00

PIPE 10

(38) 1D7-24322-00

PIPE 11

(38) 1D7-24322-00

PIPE 11

(39) 5PX-24180-00

ROLL OVER VALVE ASSY

(40) 4WM-24180-00

ROLL OVER VALVE ASSY

(41) 904641501400

CLAMP

(41) 904641501400

CLAMP

(42) 1D7-24317-00

PIPE 7

(43) 90464-10M38

CLAMP(6R8)

(44) 91314-06014

BOLT,SOCKET HEAD

(45) 1D7-26328-10

GUIDE, CABLE

(46) 920170601400

BOLT, BUTTON HEAD

(47) 1CR-26292-00

STAY

(48) 92017-05010

BOLT, BUTTON

(48) 92017-05010

BOLT, BUTTON

	Part number	Description	Qty
# 1	1D7-2172E-00 1D72172E00 1D72172E00	STAY, SIDE COVER 1	£38,58
# 2	95022-08055 9502208055 9502208055	BOLT, FLANGE	£1,58
# 3	1D7-24280-00 1D72428000 1D72428000	TANK, FUEL	£294,88
# 4	1D7-24185-00 1D72418500 1D72418500	DAMPER, LOCATING 5	£3,90
# 5	90387-0700G 903870614M00 903870700G	COLLAR	£5,75
# 6	95812-06030 95D320603000 9581206030	BOLT, FLANGE DEEP RECESS	£0,71
# 7	1D7-24305-00 1D72430500 1D72430500	FUEL PIPE JOINT COMP. 2	£113,66
# 8	90464-20010 9046420010 9046420010	CLAMP	£1,96
# 9	1D7-24311-00 1D72431100 1D72431100	PIPE, FUEL 1	£15,64
# 10	1D7-24312-00 1D72431200 1D72431200	PIPE 2	£1,58
# 11	1D7-24313-00 1D72431300 1D72431300	PIPE 3	£20,44
# 12	1D7-24314-00 1D72431400 1D72431400	PIPE 4	£23,83
# 13	5PX-2411M-00 5PX2411M00 5PX2411M00	CLIP	£7,20
# 14	90467-16009 9046716009 9046716009	CLIP	£1,98
# 15	1D7-2419F-00 1D72419F00 1D72419F00	BRACKET, CANISTOR	£32,58
# 16	90119-05004 901190580500 9011905004	BOLT, WITH WASHER	£1,55
# 17	95302-05800 9530205800 9530205800	NUT, CROWN	£0,66
# 18	1D7-13907-00 1D7139070100 1D71390700	FUEL PUMP COMP.	£1 104,00
# 19	5PX-24491-00 5PX2449100 5PX2449100	BRACKET, FUEL PUMP	£99,94
# 20	90111-05026 9011105026 9011105026	BOLT, HEX. SOCKET BUTTON	£1,39
# 21	5PX-24486-10 5PX244861100 5PX2448610	O-RING	£10,20
# 22	5PX-24145-00 5PX2414500 5PX2414500	PLATE, DAMPER	£21,18
# 23	1D7-13971-00 1D71397100 1D71397100	PIPE, FUEL 1	£71,69
# 24	90464-15004 9046415004 9046415004	CLAMP	£8,23
# 25	5PX-13973-01 5PX1397301 5PX1397301	PIPE, FUEL 3	£1,98
# 26	90467-13071 904671313300 9046713071	CLIP(3YX)	£2,09
# 27	1D7-14295-00 1D71429500 1D71429500	PIPE, FUEL	£54,92
# 28	5PX-14435-00 5PX1443500 5PX1443500	GROMMET	£7,63
# 29	5PX-14261-01 5PX1426101 5PX1426101	HOLDER	£5,02
# 30	95027-06010 9502706010 9502706010	BOLT, FLANGE(4MY)	£1,06
# 31	1D7-13974-00 1D71397400 1D71397400	PIPE, FUEL 4	£26,95
# 32	1D7-24316-10 1D72431610 1D72431610	PIPE 6	£62,53
# 33	90467-09002 9046709002 9046709002	CLIP	£1,86
# 34	90413-06002 9041306002 9041306002	WAY 3	£25,62
# 35	90413-06031 9041306031 9041306031	WAY 3	£6,70
# 36	1D7-24317-10 1D72431710 1D72431710	PIPE 7	£49,51
# 37	1D7-24321-00 1D72432100 1D72432100	PIPE 10	£12,50
# 38	1D7-24322-00 1D72432200 1D72432200	PIPE 11	£3,97
# 39	5PX-24180-00 5PX2418000 5PX2418000	ROLL OVER VALVE ASSY	£36,04
# 40	4WM-24180-00 4WM2418000 4WM2418000	ROLL OVER VALVE ASSY	£28,68
# 41	90461-15139 904641501400 9046115139	CLAMP	£2,15
# 42	1D7-24317-00 1D72431700 1D72431700	PIPE 7	£46,13
# 43	90464-10M38 9046410M38 9046410M38	CLAMP(6R8)	£2,82
# 44	91314-06014 9131406014 9131406014	BOLT, SOCKET HEAD	£0,77
# 45	1D7-26328-10 1D72632810 1D72632810	GUIDE, CABLE	£24,04
# 46	90111-06010 920170601400 9011106010	BOLT, BUTTON HEAD	£1,44
# 47	1CR-26292-00 1CR2629200 1CR2629200	STAY	£119,60
# 48	92017-05010 9201705010 9201705010	BOLT, BUTTON	£1,20

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
