ENGINE MOUNT

ENGINE HATCH 1 FOR YAMAHA FX CRUISER HO 2021

ENGINE HATCH 2

Item numbers

PACKING 4

F1KU266C0000

F1KU266C1000

£3,32

Unit Price Incl. Tax

HOOK, LID LOCK

F3XU517F0000 F3XU517F0000

£31,04

Unit Price Incl. Tax

NUT

F3XU517E0000 F3XU517E0000

£3,16

Unit Price Incl. Tax

BOLT, WITH WASHER

901190688000

901190680300

£1,50

Unit Price Incl. Tax

BRACKET

F2CU826C0000 F2CU826C0000

£6,02

Unit Price Incl. Tax

RIVET, BLIND (EW2)

90267489U200

902674894000

£1,48

Unit Price Incl. Tax

BOX GLOVE

F3XU516P0000 F3XU516P0000

£236,21

Unit Price Incl. Tax

SEAL

F3XU27230000 F3XU27230000

£5,92

Unit Price Incl. Tax

LOCK

F3XU28750100 F3XU28750100

£33,41

Unit Price Incl. Tax

NUT

F3XU517E0000 F3XU517E0000

£3,16

Unit Price Incl. Tax

INNER, CASE

F3XU591L0000 F3XU591L0000

£69,17

Unit Price Incl. Tax

BOLT, WITH WASHER

901190882200

901190882800

£3,40

Unit Price Incl. Tax

LID HATCH

F3XU517H0000 F3XU517H0000

£43,84

Unit Price Incl. Tax

PACKING CASE

F3XU519D0100 F3XU519D0100

£23,62

Unit Price Incl. Tax

COVER, CENTER

F3XU55540100 F3XU55540100

£166,12

Unit Price Incl. Tax

PLATE, FIX

F2XU51750000 F2XU51750000

£2,39

Unit Price Incl. Tax

RIVET (EU0)

90267489U100

902674893800

£1,48

Unit Price Incl. Tax

BOLT, WITH WASHER

901190685800

90119068B800

£6,01

Unit Price Incl. Tax

MAT

F3XU38440000 F3XU38440000

£5,17

Unit Price Incl. Tax

SCREW

F3XU78231200

F3XU78231100

£2,17

Unit Price Incl. Tax

WASHER, PLATE

902010680500 902010680500

£0,71

Unit Price Incl. Tax

GROMMET

F3XU13380000 F3XU13380000

£2,98

Unit Price Incl. Tax

COLLAR

F3XU151R0000 F3XU151R0000

£2,59

Unit Price Incl. Tax

BOLT

F3XU13550000 F3XU13550000

£1,18

Unit Price Incl. Tax

COVER METER

F3XU82620000 F3XU82620000

£35,99

Unit Price Incl. Tax

ORNAMENT, METER

F3XU826F0000 F3XU826F0000

£46,90

Unit Price Incl. Tax

SCREW

F2SU13C10000 F2SU13C10000

£2,88

Unit Price Incl. Tax

NUT

F3XU517E0000 F3XU517E0000

£3,16

Unit Price Incl. Tax

FIX, PLATE

F3XUE1750000 F3XUE1750000

£16,43

Unit Price Incl. Tax

SCREW

F3XU78231200

F3XU78231100

£2,17

Unit Price Incl. Tax

NUT

F3XU517E0000 F3XU517E0000

£3,16

Unit Price Incl. Tax

PACKING

F2CU17430000 F2CU17430000

£1,82

Unit Price Incl. Tax

COVER, SIDE 1

F3XU377B00P7 F3XU377B00P7

£311,41

Unit Price Incl. Tax

CUSHION, RUBBER

F1WU37680100 F1WU37680100

£3,56

Unit Price Incl. Tax

NUT

F3XU517E0000 F3XU517E0000

£3,16

Unit Price Incl. Tax

SCREW

F3XU78231200

F3XU78231100

£2,17

Unit Price Incl. Tax

WASHER, PLATE

902010680500 902010680500

£0,71

Unit Price Incl. Tax

NUT, LOCK

F2NU142L0000 F2NU142L0000

£1,14

Unit Price Incl. Tax

COVER, SIDE 2

F3XU377C00P7 F3XU377C00P7

£311,41

Unit Price Incl. Tax

CUSHION, RUBBER

F1WU37680100 F1WU37680100

£3,56

Unit Price Incl. Tax

NUT

F3XU517E0000 F3XU517E0000

£3,16

Unit Price Incl. Tax

SCREW

F3XU78231200

F3XU78231100

£2,17

Unit Price Incl. Tax

WASHER, PLATE

902010680500 902010680500

£0,71

Unit Price Incl. Tax

NUT, LOCK

F2NU142L0000 F2NU142L0000

£1,14

Unit Price Incl. Tax

SIDE ORNAMENT ASSY

F3XU370J2000 F3XU370J2000

£150,26

Unit Price Incl. Tax

SCREW

F3XU78230200 F3XU78230200

£2,46

Unit Price Incl. Tax

PLATE, FIX

F2XU51750000 F2XU51750000

£2,39

Unit Price Incl. Tax

SCREW

F3XU78231200

F3XU78231100

£2,17

Unit Price Incl. Tax

WASHER, PLATE

902010680500 902010680500

£0,71

Unit Price Incl. Tax

NUT, LOCK

F2NU142L0000 F2NU142L0000

£1,14

Unit Price Incl. Tax

SIDE ORNAMENT ASSY

F3XU370K2000 F3XU370K2000

£150,26

Unit Price Incl. Tax

SCREW

F3XU78230200 F3XU78230200

£2,46

Unit Price Incl. Tax

PLATE, FIX

F2XU51750000 F2XU51750000

£2,39

Unit Price Incl. Tax

SCREW

F3XU78231200

F3XU78231100

£2,17

Unit Price Incl. Tax

WASHER, PLATE

902010680500 902010680500

£0,71

Unit Price Incl. Tax

NUT, LOCK

F2NU142L0000 F2NU142L0000

£1,14

Unit Price Incl. Tax

PROTECTOR

F3XU895D0000 F3XU895D0000

£8,33

Unit Price Incl. Tax

MAT 2

F1KU759C0000 F1KU759C0000

£3,54

Unit Price Incl. Tax

BOX, FIRE EXTINGUI

F1KU59830100 F1KU59830100

£24,24

Unit Price Incl. Tax

BAND 1

F2PU828K0000 F2PU828K0000

£9,83

Unit Price Incl. Tax

HOOK A

F1KU57720400 F1KU57720400

£5,64

Unit Price Incl. Tax

RIVET (EU0)

90267489U100

902674893800

£1,48

Unit Price Incl. Tax

PAD, BATTERY

F1SU82210000 F1SU82210000

£4,45

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
