STEERING

FRONT FORK FOR YAMAHA FJR1300A 2015

FUEL TANK

(1) 1MC-23102-00

FRONT FORK ASSY (L.H)

(2) 3P6-23110-11

INNER TUBE COMP.1

(3) 4SV-23135-10

METAL, SLIDE 2

(4) 1MC-23126-00

TUBE, OUTER (LEFT)

(5) 4SV-23125-10

METAL, SLIDE 1

(6) 3P6-23135-00

METAL, SLIDE 2

(7) 4SV-23144-00

SEAL, DUST

(8) 4SV-23145-01

OIL SEAL

(9) 4SV-23115-00

SEAT 1

(10) 4SV-23156-00

CLIP, OIL SEAL

(11) 1MC-2315K-00

CYL. COMP.,2

(12) 90110-10N52

BOLT, HEXAGON SOCKET HEAD

(13) 90430-10171

GASKET (5R6)

(14) 1MC-23141-00

SPRING, FRONT FORK

(15) 90201-140J1

WASHER, PLATE

(15) 90201-140J1

WASHER, PLATE

(16) 1MC-23118-00

SPACER

(17) 1MC-23111-00

BOLT, CAP

(18) 93210-40N50

O-RING(4SV)

(19) 4SV-2331G-00

COVER

(20) 91314-08045

BOLT,SOCKET

(21) 1MC-23103-00

FRONT FORK ASSY (R.H)

(22) 3P6-23110-11

INNER TUBE COMP.1

(23) 4SV-23135-10

METAL, SLIDE 2

(24) 3P6-23107-01

OUTER TUBE COMP. (R.H)

(25) 4SV-23125-10

METAL, SLIDE 1

(26) 3P6-23135-00

METAL, SLIDE 2

(27) 4SV-23144-00

SEAL, DUST

(28) 4SV-23145-01

OIL SEAL

(29) 4SV-23115-00

SEAT 1

(30) 4SV-23156-00

CLIP, OIL SEAL

(31) 1MC-2315L-00

CYL. COMP.,3

(32) 90110-10N52

BOLT, HEXAGON SOCKET HEAD

(33) 90430-10171

GASKET (5R6)

(34) 1MC-23141-00

SPRING, FRONT FORK

(35) 90201-10321

WASHER, PLATE (856)

(36) 1MC-23118-10

SPACER

(37) 1MC-2311J-00

BOLT, CAP 2

(38) 93210-40N50

O-RING(4SV)

(39) 5JW-2319W-00

KNOB (TEN)

(40) 986800300800

SCREW, OVAL HEAD

(41) 953141060000

NUT(3BM)

(42) 4SV-2331G-00

COVER

(43) 91314-08045

BOLT,SOCKET

(44) 1MC233401000

UNDER BRACKET COMP.

(45) 913170802500

BOLT, SOCKET

(45) 913170802500

BOLT, SOCKET

	Part number	Description	Qty
# 1	1MC-23102-00 1MC2310200 1MC2310200	FRONT FORK ASSY (L.H)	Not available	£0,00
# 2	3P6-23110-11 3P62311011 3P62311011	INNER TUBE COMP.1	£384,61
# 3	4SV-23135-10 4SV2313510 4SV2313510	METAL, SLIDE 2	£17,24
# 4	1MC-23126-00 1MC2312600 1MC2312600	TUBE, OUTER (LEFT)	£398,39
# 5	4SV-23125-10 4SV2312510 4SV2312510	METAL, SLIDE 1	£17,59
# 6	3P6-23135-00 3P62313500 3P62313500	METAL, SLIDE 2	£17,50
# 7	4SV-23144-00 4SV2314400 4SV2314400	SEAL, DUST	£15,38
# 8	4SV-23145-01 4SV2314501 4SV2314501	OIL SEAL	£14,41
# 9	4SV-23115-00 4SV2311500 4SV2311500	SEAT 1	£5,20
# 10	4SV-23156-00 4SV2315600 4SV2315600	CLIP, OIL SEAL	£1,56
# 11	1MC-2315K-00 1MC2315K00 1MC2315K00	CYL. COMP., 2	£316,49
# 12	90110-10N52 9011010N52 9011010N52	BOLT, HEXAGON SOCKET HEAD	£6,11
# 13	90430-10171 9043010171 9043010171	GASKET (5R6)	£3,73
# 14	1MC-23141-00 1MC2314100 1MC2314100	SPRING, FRONT FORK	£36,85
# 15	90201-140J1 90201140J1 90201140J1	WASHER, PLATE	£2,09
# 16	1MC-23118-00 1MC2311800 1MC2311800	SPACER	£8,32
# 17	1MC-23111-00 1MC2311100 1MC2311100	BOLT, CAP	£86,54
# 18	93210-40N50 9321040N50 9321040N50	O-RING(4SV)	£2,81
# 19	4SV-2331G-00 4SV2331G00 4SV2331G00	COVER	£12,86
# 20	91314-08045 9131408045 9131408045	BOLT, SOCKET	£5,41
# 21	1MC-23103-00 1MC2310300 1MC2310300	FRONT FORK ASSY (R.H)	Not available	£0,00
# 22	3P6-23110-11 3P62311011 3P62311011	INNER TUBE COMP.1	£384,61
# 23	4SV-23135-10 4SV2313510 4SV2313510	METAL, SLIDE 2	£17,24
# 24	3P6-23107-01 3P62310701 3P62310701	OUTER TUBE COMP. (R.H)	£398,39
# 25	4SV-23125-10 4SV2312510 4SV2312510	METAL, SLIDE 1	£17,59
# 26	3P6-23135-00 3P62313500 3P62313500	METAL, SLIDE 2	£17,50
# 27	4SV-23144-00 4SV2314400 4SV2314400	SEAL, DUST	£15,38
# 28	4SV-23145-01 4SV2314501 4SV2314501	OIL SEAL	£14,41
# 29	4SV-23115-00 4SV2311500 4SV2311500	SEAT 1	£5,20
# 30	4SV-23156-00 4SV2315600 4SV2315600	CLIP, OIL SEAL	£1,56
# 31	1MC-2315L-00 1MC2315L00 1MC2315L00	CYL. COMP., 3	Not available	£0,00
# 32	90110-10N52 9011010N52 9011010N52	BOLT, HEXAGON SOCKET HEAD	£6,11
# 33	90430-10171 9043010171 9043010171	GASKET (5R6)	£3,73
# 34	1MC-23141-00 1MC2314100 1MC2314100	SPRING, FRONT FORK	£36,85
# 35	90201-10321 9020110321 9020110321	WASHER, PLATE (856)	£6,11
# 36	1MC-23118-10 1MC2311810 1MC2311810	SPACER	£8,32
# 37	1MC-2311J-00 1MC2311J00 1MC2311J00	BOLT, CAP 2	£134,89
# 38	93210-40N50 9321040N50 9321040N50	O-RING(4SV)	£2,81
# 39	5JW-2319W-00 5JW2319W00 5JW2319W00	KNOB (TEN)	£6,49
# 40	90142-03N01 986800300800 9014203N01	SCREW, OVAL HEAD	£2,23
# 41	95302-10600 953141060000 9530210600	NUT(3BM)	£1,44
# 42	4SV-2331G-00 4SV2331G00 4SV2331G00	COVER	£12,86
# 43	91314-08045 9131408045 9131408045	BOLT, SOCKET	£5,41
# 44	3P6-23340-01 1MC233401000 3P62334001	UNDER BRACKET COMP.	£554,75
# 45	91312-08025 913170802500 9131208025	BOLT, SOCKET	£1,69

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the FRONT FORK of your Yamaha FJR1300A of 2015. Let us know if you have any questions.
