SIDE COVER FOR YAMAHA XVZ1300A 1998

SWINGARM

CACHE LATERALE 1

4NK217110033 4NK217110033

Not available

CACHE LATERALE 1

4NK2171100FE 4NK2171100FE

Not available

CACHE LATERALE 1

4NK2171100HK 4NK2171100HK

Not available

DAMPER 2

51Y216390000 51Y216390000

£1,26

Unit Price Incl. Tax

SCREW(3XV)

901490629800 901490629800

£4,88

Unit Price Incl. Tax

WASHER, PLATE(J38)

902020617200

902020617000

£2,54

Unit Price Incl. Tax

GROMMET(4FU)

904801356700 904801356700

£8,15

Unit Price Incl. Tax

CACHE LATERALE 2

4NK217210033 4NK217210033

Not available

CACHE LATERALE 2

4NK2172100FE 4NK2172100FE

Not available

CACHE LATERALE 2

4NK2172100HK 4NK2172100HK

Not available

DAMPER 2

51Y216390000 51Y216390000

£1,26

Unit Price Incl. Tax

SCREW(3XV)

901490629800 901490629800

£4,88

Unit Price Incl. Tax

WASHER, PLATE(J38)

902020617200

902020617000

£2,54

Unit Price Incl. Tax

GROMMET(4FU)

904801356700 904801356700

£8,15

Unit Price Incl. Tax

SEAL, 2

1JK217350000 1JK217350000

£4,88

Unit Price Incl. Tax

COUVERCLE 9

4NK2117X0033 4NK2117X0033

Not available

COUVERCLE 9

4NK2117X00FE 4NK2117X00FE

Not available

COUVERCLE 9

4NK2117X00HK 4NK2117X00HK

Not available

PROTECTOR

52W2117G0000 52W2117G0000

£9,56

Unit Price Incl. Tax

SCREW, PAN HEAD(3TJ)

901590608400

985070601600

£0,49

Unit Price Incl. Tax

SCREW(3XV)

901490629800 901490629800

£4,88

Unit Price Incl. Tax

WASHER, PLATE(J38)

902020617200

902020617000

£2,54

Unit Price Incl. Tax

NUT, FLANGE(4MV)

957070650000 957070650000

£4,39

Unit Price Incl. Tax

BOLT, HEXAGON

970070602000

970170602000

£1,50

Unit Price Incl. Tax

COLLAR(1LJ)

90387067N500 90387067N500

£6,59

Unit Price Incl. Tax

GROMMET

904801339800

904801301400

£1,91

Unit Price Incl. Tax

BOX, BATTERY

4NK2177G0000 4NK2177G0000

£82,68

Unit Price Incl. Tax

GROMMET(42X)

904802038400 904802038400

£5,84

Unit Price Incl. Tax

GROMMET

904801339800

904801301400

£1,91

Unit Price Incl. Tax

COLLAR(1LJ)

90387067N500 90387067N500

£6,59

Unit Price Incl. Tax

BOLT, WITH WASHER (10V)

901190609600

901190606300

£2,26

Unit Price Incl. Tax

TANK, RECOVERY

4NK218710000 4NK218710000

Not available

BOLT, WITH WASHER

901190604400

901190624200

£1,28

Unit Price Incl. Tax

GROMMET(4FU)

904801356700 904801356700

£8,15

Unit Price Incl. Tax

CAP

4NK218750000

1B7218750000

£26,03

Unit Price Incl. Tax

ELBOW

26H218280000 26H218280000

£9,16

Unit Price Incl. Tax

CLIP(72X)

904671101900

9046711M0800

£1,85

Unit Price Incl. Tax

HOSE (L545)

904450911700

Not available

CLIP

904670900600

90467090A200

£0,55

Unit Price Incl. Tax

PLATE, BRIDGE

4NK212430000

4NK212430100

£173,98

Unit Price Incl. Tax

BOLT, FLANGE

958070601000

958170601000

£0,49

Unit Price Incl. Tax

BRACKET, FUEL PUMP

3CV244911000 3CV244911000

£34,54

Unit Price Incl. Tax

BOLT, FLANGE

958170601600 958170601600

£0,71

Unit Price Incl. Tax

COLLAR(42G)

90387062L200 90387062L200

£4,94

Unit Price Incl. Tax

GROMMET (1E5)

904801316300 904801316300

£2,26

Unit Price Incl. Tax

SCREW, BINDING

989070501000 989070501000

£1,14

Unit Price Incl. Tax

COVER, SIDE 3

4NK217310000 4NK217310000

£25,03

Unit Price Incl. Tax

SCREW, PAN HEAD(3TJ)

901590607100

985070601600

£0,49

Unit Price Incl. Tax

GROMMET(4FU)

904801356700 904801356700

£8,15

Unit Price Incl. Tax

COVER, SIDE 4

4NK217410000 4NK217410000

£25,03

Unit Price Incl. Tax

SCREW, PAN HEAD(3TJ)

901590607100

985070601600

£0,49

Unit Price Incl. Tax

GROMMET(4FU)

904801356700 904801356700

£8,15

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the SIDE COVER of your Yamaha XVZ1300A of 1998. Let us know if you have any questions.
