FRAME FOR YAMAHA XVZ13ATH 1996

FENDER

CADRE COMP.

4NK211100033 4NK211100033

Not available

TUBE INCLINE COMP. 2

4NK211500033 4NK211500033

Not available

BOLT, SOCKET

901101012600

913171003000

£4,69

Unit Price Incl. Tax

CADRE, ARRIERE

4NK211200033 4NK211200033

Not available

BOLT, SOCKET

901101012600

913171003000

£4,69

Unit Price Incl. Tax

BOLT, SOCKET

901101019100

913171002500

£3,42

Unit Price Incl. Tax

ENTRETOISE AVANT

4NK2141V0000 4NK2141V0000

Not available

BOLT, FLANGE(7LU)

958271007000

958171007000

£5,95

Unit Price Incl. Tax

BOLT, FLANGE

958271008000

958171008000

£4,74

Unit Price Incl. Tax

NUT, CROWN(2GG)

901761007500 901761007500

£3,82

Unit Price Incl. Tax

WASHER(6TA)

929071060000 929071060000

£0,49

Unit Price Incl. Tax

NUT (22F)

957071050000

901791039400

£3,00

Unit Price Incl. Tax

BOLT, WASHER BASED(4EB)

901051078800 901051078800

£7,13

Unit Price Incl. Tax

RONDELLE

902091234100 902091234100

Not available

BOLT, WASHER BASED(4EB)

901051078800 901051078800

£7,13

Unit Price Incl. Tax

BOLT, WASHER BASED (26H)

901051225200 901051225200

£7,46

Unit Price Incl. Tax

REAR FRAME COMP.

4NK211900000

4XY211900200

£933,14

Unit Price Incl. Tax

BOLT, WASHER BASED (2H9)

958171003500

901051011500

£8,52

Unit Price Incl. Tax

RIVET(4JH)

902690707600 902690707600

£1,42

Unit Price Incl. Tax

COUVERCLE

4NK2117F0000 4NK2117F0000

Not available

RIVET(52W)

902690504900 902690504900

£1,42

Unit Price Incl. Tax

COUVERCLE 2

4NK2117M0100 4NK2117M0100

Not available

SCREW, TRUSS TAP.

977076001600 977076001600

£0,49

Unit Price Incl. Tax

CACHE LATERALE

4NK2171E0033 4NK2171E0033

Not available

CACHE, LATERALE 6

4NK2171X0033 4NK2171X0033

Not available

BOLT(4TW)

970070501600

970170501600

£0,94

Unit Price Incl. Tax

WASHER

902090617400

902090601200

£0,68

Unit Price Incl. Tax

RIVET(4JH)

902690707600 902690707600

£1,42

Unit Price Incl. Tax

DAMPER, PLATE 2

1LJ2414J0000 1LJ2414J0000

£1,21

Unit Price Incl. Tax

SUPPORT, POT D ECHAPPEMENT 1

4NK214450000 4NK214450000

Not available

SUPPORT, POT D ECHAPPEMENT 2

4NK214460000 4NK214460000

Not available

BOLT, WASHER BASED(36Y)

901050831000 901050831000

£4,30

Unit Price Incl. Tax

DAMPER, FOOTREST 2

36Y274240000

36Y274240100

£4,58

Unit Price Incl. Tax

COLLAR

90387104L800

903871004800

£10,61

Unit Price Incl. Tax

WASHER, PLATE (4X7)

90201105A200 90201105A200

£3,00

Unit Price Incl. Tax

BOLT, SOCKET

913171004000 913171004000

£4,48

Unit Price Incl. Tax

NUT(6TD)

953171060000

953371060000

£4,48

Unit Price Incl. Tax

CLAMP(4GY)

904642019100 904642019100

£3,52

Unit Price Incl. Tax

BRIDE

4NK825940000 4NK825940000

Not available

BOLT, SOCKET

913170601000 913170601000

£1,24

Unit Price Incl. Tax

PROTECTEUR

4NK2117G0000 4NK2117G0000

Not available

STEERING LOCK ASSY

2A6234080000 2A6234080000

£40,32

Unit Price Incl. Tax

SPRING, CONICAL (1E6)

905020902400 905020902400

£2,44

Unit Price Incl. Tax

CAP, HANDLE LOCK

584234840100

3DM234840000

£15,30

Unit Price Incl. Tax

RIVET 214234830000

902690400300 902690400300

£1,42

Unit Price Incl. Tax

WASHER, CONICAL SPRING (3J3)

902080402900 902080402900

£0,49

Unit Price Incl. Tax

TROUSSE A OUTILS

4NK281000000 4NK281000000

Not available

O-RING (70E)

932105453400 932105453400

£2,58

Unit Price Incl. Tax

BOITIER A OUTILS

4NK281730000 4NK281730000

Not available

BRACKET, CANISTER

4NK2134X0000 4NK2134X0000

Not available

BOLT, FLANGE

958170601200 958170601200

£1,42

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the FRAME of your Yamaha XVZ13ATH of 1996. Let us know if you have any questions.
