OIL TANK

SWINGARM FOR YAMAHA DTX 125 SM 2005

REAR SHOCK ABSORBER

Item numbers

REAR ARM COMP.

4TP221100198 4TP221100198

Not available

BEARING, CYLINDRICAL(4PT)

933152225100 933152225100

£38,05

Unit Price Incl. Tax

BUSH, SOLID (23X)

903802211100 903802211100

£15,95

Unit Price Incl. Tax

OIL SEAL (23X)

931062201900 931062201900

£5,81

Unit Price Incl. Tax

WASHER, PLATE(30X)

90201254H800 90201254H800

£3,42

Unit Price Incl. Tax

OIL SEAL (35X41.5X8-483)

931083500400 931083500400

£6,91

Unit Price Incl. Tax

COVER

30X2219X0000 30X2219X0000

£9,17

Unit Price Incl. Tax

BUSH, SOLID (3R4)

903801607700 903801607700

£28,68

Unit Price Incl. Tax

WASHER, PLATE (5Y1)

90201251F600 90201251F600

£1,92

Unit Price Incl. Tax

SHAFT, PIVOT

3R4221410000

5X6221410100

£40,40

Unit Price Incl. Tax

WASHER, PLATE(33Y)

90201164H400 90201164H400

£3,42

Unit Price Incl. Tax

NUT, U (6TD)

901851612700

956171610000

£16,31

Unit Price Incl. Tax

BRAS DE LIAISON

3BN2217A1000 3BN2217A1000

Not available

BEARING, CYLINDRICAL(4RR)

933153205200 933153205200

£35,82

Unit Price Incl. Tax

OIL SEAL

931092007600 931092007600

£6,44

Unit Price Incl. Tax

COLLAR(3BN)

90387164U700 90387164U700

£20,58

Unit Price Incl. Tax

NUT, UNION(1LV)

904021000500 904021000500

Not available

WASHER, PLATE (17K)

90201106F200 90201106F200

£2,44

Unit Price Incl. Tax

BOLT, FLANGE(3HP)

958171001600 958171001600

£3,12

Unit Price Incl. Tax

BUSH (30X)

903862012000 903862012000

£17,56

Unit Price Incl. Tax

OIL SEAL

931092007600 931092007600

£6,44

Unit Price Incl. Tax

ROD, CONNECTING 1

3BN2217F0000 3BN2217F0000

£21,79

Unit Price Incl. Tax

COLLAR(3BN)

90387164U800 90387164U800

£26,95

Unit Price Incl. Tax

BOLT, UNION(2WG)

904011413600 904011413600

£38,58

Unit Price Incl. Tax

WASHER, PLATE (5X6)

90201160F600 90201160F600

£5,60

Unit Price Incl. Tax

NUT, SELF-LOCKING

901851411200 901851411200

£10,10

Unit Price Incl. Tax

NIPPLE, GREASE(6A1)

937000600400

9370006M0300

£5,00

Unit Price Incl. Tax

CARTER, CHAINE

2C8F23110000 2C8F23110000

Not available

BOLT, WITH WASHER(55K)

901190611700 901190611700

£1,64

Unit Price Incl. Tax

SEAL, GUARD

1LN221510000 1LN221510000

£90,92

Unit Price Incl. Tax

BOLT, WITH WASHER (10V)

901190609600

901190606300

£2,16

Unit Price Incl. Tax

WASHER (3R8)

902090618700 902090618700

£2,16

Unit Price Incl. Tax

GUARD, CHAIN

34X221530000 34X221530000

£15,70

Unit Price Incl. Tax

BOLT, FLANGE

958070605000

958170605000

£1,92

Unit Price Incl. Tax

BOLT, FLANGE

950270606000

950220606000

£0,29

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
