RADIATOR / HOSES FOR YAMAHA VMX12 1994

OIL PUMP

(1) 1FK-12578-00

HOSE 3

(2) 904503804000

HOSE CLAMP ASSY(3GM)

(3) 90338-05151

PLUG (32N)

(4) 1FK-12620-00

AIR SHROUD ASSY

(5) 26H-12630-00

MOTOR ASSY

(6) 26H-12611-00

FAN

(7) 98580-05008

SCREW, PAN HEAD (7G3)

(8) 9290L0560000

WASHER

(9) 95380-05600

NUT, HEXAGON (663)

(10) 11H-12673-00

WASHER

(11) 92990-05300

WASHER, TOOTH

(12) 901190624200

BOLT, WITH WASHER

(12) 901190624200

BOLT, WITH WASHER

(13) 90480-14052

GROMMET (431)

(14) 90480-18276

GROMMET (4L0)

(15) 90387-07037

COLLAR 8111266500

(16) 90480-19283

GROMMET (4L0)

(17) 90387-06033

COLLAR(735)

(18) 970170602000

BOLT, HEXAGON

(18) 970170602000

BOLT, HEXAGON

(19) 929070610000

WASHER, SPRING

(19) 929070610000

WASHER, SPRING

(20) 1FK-12467-00

COVER, RADIATOR

(21) 98516-05012

VIS, TETE TRONCONIQUE

(22) 929070510000

WASHER(3SX)

(23) 9290M0560000

WASHER, PLAIN

(24) 1FK-1240J-00

RADIATOR COVER ASSY

(25) 1FK-12535-00

PLATE

(26) 1FK-1240K-00

RADIATOR COVER ASSY 2

(27) 1FK-12537-00

PLATE 2

(28) 985070501600

SCREW, PAN HEAD(JJ6)

(29) 1FK-12560-01

DRAIN COCK ASSY.

(30) 932101457900

O-RING (26H)

(31) 1FK-12566-00

PIPE, BYPASS

(32) 90501-106A4

SPRING, COMPRESSION(1FK)

(33) 90460-15227

BAND (MADE IN CANADA)

(33) 90460-15227

BAND (MADE IN CANADA)

(34) 90445090F600

HOSE (L1500)

(35) 904670800300

CLIP 101235600

(35) 904670800300

CLIP 101235600

(36) 1FK-12576-00

HOSE 1

(37) 1FK-12577-00

HOSE 2

(38) 90467-23067

CLIP (10V)

(38) 90467-23067

CLIP (10V)

(38) 90467-23067

CLIP (10V)

(38) 90467-23067

CLIP (10V)

(39) 1FK-12579-00

HOSE 4

(40) 90501-106A5

SPRING, COMPRESSION(1FK)

(41) 904503804000

HOSE CLAMP ASSY(3GM)

(41) 904503804000

HOSE CLAMP ASSY(3GM)

(42) 1FK-12479-01

JOINT

(43) 978850603000

SCREW, PAN HEAD(6E0)

(44) 9290M0660000

WASHER,PLAIN

(45) 1FK125910000

SUPT, FILLER NECK

(46) 4FL124620000

CAP, RADIATOR

(47) 93210-27778

O-RING(1KT)

(48) 98580-06016

SCREW PAN HEAD

(49) 92995-06100

WASHER(6A1)

(50) 9290M0660000

WASHER,PLAIN

(51) 1FK-1246A-01

COUVERCLE 1

(52) 1FK-1246E-01

COUVERCLE 2

(53) 26H-12428-00

GASKET, HOUSING COVER 2

(54) 913170601800

BOLT,SOCKET

(55) 26H-12427-00

GASKET, HOUSING COVER 1

(56) 1FK-11166-00

PIPE, BREATHER 1

(57) 90467-14015

CLIP (371)

(57) 90467-14015

CLIP (371)

(58) 913170604000

BOLT,SOCKET

(59) 1FK-12589-00

HOSE, 6

(60) 904671013500

CLIP(3BM)

(60) 904671013500

CLIP(3BM)

(61) 26H-12588-01

HOSE 5

(62) 90460-15227

BAND (MADE IN CANADA)

(62) 90460-15227

BAND (MADE IN CANADA)

(63) 1FK-1246K-00

COVER, 7

(64) 1FK-12461-00

RADIATOR ASSY

(65) 1AA-12535-00

PLATE

	Part number	Description	Qty
# 1	1FK-12578-00 1FK1257800 1FK1257800	HOSE 3	£20,64
# 2	90460-38285 904503804000 9046038285	HOSE CLAMP ASSY(3GM)	£10,58
# 3	90338-05151 9033805151 9033805151	PLUG (32N)	£2,09
# 4	1FK-12620-00 1FK1262000 1FK1262000	AIR SHROUD ASSY	£217,87
# 5	26H-12630-00 26H1263000 26H1263000	MOTOR ASSY	Not available	£0,00
# 6	26H-12611-00 26H1261100 26H1261100	FAN	£157,67
# 7	98580-05008 9858005008 9858005008	SCREW, PAN HEAD (7G3)	£1,56
# 8	92901-05600 9290105600	WASHER	Not available	£0,00
# 9	95380-05600 9538005600 9538005600	NUT, HEXAGON (663)	£2,09
# 10	11H-12673-00 11H1267300 11H1267300	WASHER	£1,30
# 11	92990-05300 9299005300 9299005300	WASHER, TOOTH	£2,35
# 12	90119-06044 901190624200 9011906044	BOLT, WITH WASHER	£1,20
# 13	90480-14052 9048014052 9048014052	GROMMET (431)	£4,32
# 14	90480-18276 9048018276 9048018276	GROMMET (4L0)	£1,32
# 15	90387-07037 9038707037 9038707037	COLLAR 8111266500	£6,24
# 16	90480-19283 9048019283 9048019283	GROMMET (4L0)	£3,72
# 17	90387-06033 9038706033 9038706033	COLLAR(735)	£2,62
# 18	97016-06020 970170602000 9701606020	BOLT, HEXAGON	£1,44
# 19	92906-06100 929070610000 9290606100	WASHER, SPRING	£0,59
# 20	1FK-12467-00 1FK1246700 1FK1246700	COVER, RADIATOR	Not available	£0,00
# 21	98516-05012 9851605012 9851605012	VIS, TETE TRONCONIQUE	Not available	£0,00
# 22	92906-05100 929070510000 9290605100	WASHER(3SX)	£0,48
# 23	92906-05600 9290M0560000 9290605600	WASHER, PLAIN	£0,31
# 24	1FK-1240J-00 1FK1240J00 1FK1240J00	RADIATOR COVER ASSY	£81,07
# 25	1FK-12535-00 1FK1253500 1FK1253500	PLATE	£16,25
# 26	1FK-1240K-00 1FK1240K00 1FK1240K00	RADIATOR COVER ASSY 2	£81,07
# 27	1FK-12537-00 1FK1253700 1FK1253700	PLATE 2	£16,25
# 28	90159-05073 985070501600 9015905073	SCREW, PAN HEAD(JJ6)	£0,48
# 29	1FK-12560-01 1FK1256001 1FK1256001	DRAIN COCK ASSY.	£76,37
# 30	93210-14104 932101457900 9321014104	O-RING (26H)	£1,02
# 31	1FK-12566-00 1FK1256600 1FK1256600	PIPE, BYPASS	£42,74
# 32	90501-106A4 90501106A4 90501106A4	SPRING, COMPRESSION(1FK)	£15,36
# 33	90460-15227 9046015227 9046015227	BAND (MADE IN CANADA)	£13,03
# 34	90445-09112 90445090F600 9044509112	HOSE (L1500)	£7,76
# 35	904670800300 904670800300 904670800300	CLIP 101235600	£1,98
# 36	1FK-12576-00 1FK1257600 1FK1257600	HOSE 1	£30,88
# 37	1FK-12577-00 1FK1257700 1FK1257700	HOSE 2	£40,64
# 38	90467-23067 9046723067 9046723067	CLIP (10V)	£4,32
# 39	1FK-12579-00 1FK1257900 1FK1257900	HOSE 4	£23,75
# 40	90501-106A5 90501106A5 90501106A5	SPRING, COMPRESSION(1FK)	£6,49
# 41	90460-38285 904503804000 9046038285	HOSE CLAMP ASSY(3GM)	£10,58
# 42	1FK-12479-01 1FK1247901 1FK1247901	JOINT	£200,50
# 43	98580-06030 978850603000 9858006030	SCREW, PAN HEAD(6E0)	£2,90
# 44	92901-06600 9290106600	WASHER, PLAIN	Not available	£0,00
# 45	1FK-12590-00 1FK1259000	SUPT, FILLER NECK	Not available	£0,00
# 46	22W-12462-00 4FL124620000 22W1246200	CAP, RADIATOR	£41,18
# 47	93210-27778 9321027778 9321027778	O-RING(1KT)	£5,57
# 48	98580-06016 9858006016 9858006016	SCREW PAN HEAD	£1,32
# 49	92995-06100 9299506100 9299506100	WASHER(6A1)	£0,16
# 50	92901-06600 9290106600	WASHER, PLAIN	Not available	£0,00
# 51	1FK-1246A-01 1FK1246A01 1FK1246A01	COUVERCLE 1	Not available	£0,00
# 52	1FK-1246E-01 1FK1246E01 1FK1246E01	COUVERCLE 2	Not available	£0,00
# 53	26H-12428-00 26H1242800 26H1242800	GASKET, HOUSING COVER 2	£11,42
# 54	91316-06018 913170601800 9131606018	BOLT, SOCKET	£1,18
# 55	26H-12427-00 26H1242700 26H1242700	GASKET, HOUSING COVER 1	£10,81
# 56	1FK-11166-00 1FK1116600 1FK1116600	PIPE, BREATHER 1	£14,18
# 57	90467-14015 9046714015 9046714015	CLIP (371)	£2,09
# 58	91316-06040 913170604000 9131606040	BOLT, SOCKET	£1,56
# 59	1FK-12589-00 1FK1258900 1FK1258900	HOSE, 6	£17,54
# 60	90467-11090 904671013500 9046711090	CLIP(3BM)	£2,09
# 61	26H-12588-01 26H1258801 26H1258801	HOSE 5	£10,12
# 62	90460-15227 9046015227 9046015227	BAND (MADE IN CANADA)	£13,03
# 63	1FK-1246K-00 1FK1246K00 1FK1246K00	COVER, 7	Not available	£0,00
# 64	1FK-12461-00 1FK1246100 1FK1246100	RADIATOR ASSY	Not available	£0,00
# 65	1AA-12535-00 1AA1253500 1AA1253500	PLATE	£13,69

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the RADIATOR / HOSES of your Yamaha VMX12 of 1994. Let us know if you have any questions.
