ELECTRICAL 1

ELECTRICAL 2 FOR YAMAHA DRAGSTAR 1100 CLASSIC 2006

RECTIFIER & REGULATOR ASSY

4XY819600000 4XY819600000

£240,73

Unit Price Incl. Tax

WASHER, PLATE (8H9)

902010672700 902010672700

£3,12

Unit Price Incl. Tax

BOLT, HEXAGON

970070602500

970170602500

£1,19

Unit Price Incl. Tax

NUT, SPRING(4ES)

901830605300

901830606900

£2,08

Unit Price Incl. Tax

WASHER, PLATE(3MB)

902020518700 902020518700

£0,49

Unit Price Incl. Tax

STARTER RELAY ASSY (RC19-003)

4DN819401200 4DN819401200

£93,86

Unit Price Incl. Tax

FUSE (12V 30A)

1AE821510000 1AE821510000

£12,73

Unit Price Incl. Tax

BOLT, SMALL FLANGE

950270600800 950270600800

£0,49

Unit Price Incl. Tax

BATTERY YU-YT14B(WC)

5EA821001100

5EA821001200

£137,16

Unit Price Incl. Tax

BAND, BATTERY

118821310000 118821310000

£15,29

Unit Price Incl. Tax

WIRE, PLUS LEAD

5EL821150000 5EL821150000

£49,09

Unit Price Incl. Tax

WIRE, MINUS LEAD

5EL821160000 5EL821160000

£32,69

Unit Price Incl. Tax

MAIN SW. IMMOBILIZER KIT

5KSW82500100

5KSW82500200

£1 399,68

Unit Price Incl. Tax

IGNITOR UNIT ASSY

5KS823050000 5KS823050000

£726,23

Unit Price Incl. Tax

IMMOBILIZER. UNIT COMP.

5KS8255P0000

5KS8255P0200

£546,23

Unit Price Incl. Tax

SCREW, PAN HEAD(JJ6)

901590518300

985070501600

£0,49

Unit Price Incl. Tax

BLANK KEY

5SL825110800 5SL825110800

£71,88

Unit Price Incl. Tax

SCREW

901490800200 901490800200

£2,26

Unit Price Incl. Tax

STOP SWITCH ASSY

5EL825300000

5EL825300100

£37,20

Unit Price Incl. Tax

WIRE HARNESS ASSY

5KS825900000 5KS825900000

Not available

FUSE (10A)

5JJ821513000

67F821514000

£8,04

Unit Price Incl. Tax

FUSE (15A)

5JJ821511000

67F821515000

£8,04

Unit Price Incl. Tax

FUSE (5A)

5JJ821519000

67F821512000

£8,04

Unit Price Incl. Tax

SWITCH, SIDE STAND

5RT825664000 5RT825664000

£54,25

Unit Price Incl. Tax

SCREW, PAN HEAD

901570507900

985070501400

£0,49

Unit Price Incl. Tax

RELAY ASSY

5KS819500000

5KS819500200

£79,25

Unit Price Incl. Tax

THERMO SWITCH ASSY

5FU825605000 5FU825605000

£22,31

Unit Price Incl. Tax

BAND

1UA825910000 1UA825910000

£1,72

Unit Price Incl. Tax

CLAMP(4GY)

904642019100 904642019100

£3,66

Unit Price Incl. Tax

CLAMP(4KM)

904642521700 904642521700

£3,83

Unit Price Incl. Tax

CLAMP(4HM)

904641519200 904641519200

£2,26

Unit Price Incl. Tax

RELAY ASSY

4XV8195A0000 4XV8195A0000

£120,29

Unit Price Incl. Tax

RELAY ASSY (5EA-02)

5EA819502000 5EA819502000

£87,25

Unit Price Incl. Tax

HOLDER, RELAY

5EA819520000 5EA819520000

£5,12

Unit Price Incl. Tax

SCREW, TRUSS TAP.

977076001600 977076001600

£0,49

Unit Price Incl. Tax

PLUG(4BP)

903380822600 903380822600

£1,43

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the ELECTRICAL 2 of your Yamaha DRAGSTAR 1100 CLASSIC of 2006. Let us know if you have any questions.
