ELECTRICAL 1

ELECTRICAL 2 FOR YAMAHA XVS1100 2000

RECTIFIER & REGULATOR ASSY

5BN819600000 5BN819600000

£180,58

Unit Price Incl. Tax

WASHER, PLATE (8H9)

902010672700 902010672700

£3,12

Unit Price Incl. Tax

BOLT, HEXAGON

970070602500

970170602500

£1,19

Unit Price Incl. Tax

NUT, SPRING(4ES)

901830605300

901830606900

£2,08

Unit Price Incl. Tax

WASHER, PLATE(3MB)

902020518700 902020518700

£0,49

Unit Price Incl. Tax

STARTER RELAY ASSY (RC19-003)

4DN819400000

4DN819401200

£93,86

Unit Price Incl. Tax

FUSE (12V 30A)

1AE821510000 1AE821510000

£12,73

Unit Price Incl. Tax

BOLT, SMALL FLANGE

950270600800 950270600800

£0,49

Unit Price Incl. Tax

BATTERY YU-YT14B(WC)

5EA821001000

5EA821001200

£137,16

Unit Price Incl. Tax

BAND, BATTERY

118821310000 118821310000

£15,29

Unit Price Incl. Tax

WIRE, PLUS LEAD

5EL821150000 5EL821150000

£49,09

Unit Price Incl. Tax

WIRE, MINUS LEAD

5EL821160000 5EL821160000

£32,69

Unit Price Incl. Tax

MAIN SWITCH STEERING LOCK

4VR825010000

Not available

BOLT, BUTTON

920170802000 920170802000

£2,26

Unit Price Incl. Tax

STOP SWITCH ASSY

5EL825300000

5EL825300100

£37,20

Unit Price Incl. Tax

FAISCEAU DE FILS COMPLET

5EL825900000 5EL825900000

Not available

FUSE

1NL821510000 1NL821510000

£4,67

Unit Price Incl. Tax

FUSE (12V 15A)

36Y821510000 36Y821510000

£3,97

Unit Price Incl. Tax

FUSE (10A)

42X821510000 42X821510000

£5,22

Unit Price Incl. Tax

SWITCH, SIDE STAND

3LD825664000

3LD825664100

£81,61

Unit Price Incl. Tax

SCREW, PAN HEAD

901570507900

985070501400

£0,49

Unit Price Incl. Tax

RELAY ASSY

3EN819500000

3EN819500200

£101,03

Unit Price Incl. Tax

THERMO SWITCH ASSY

4TR825600000 4TR825600000

BAND

1UA825910000 1UA825910000

£1,72

Unit Price Incl. Tax

CLAMP(4GY)

904642019100 904642019100

£3,66

Unit Price Incl. Tax

CLAMP(4KM)

904642521700 904642521700

£3,83

Unit Price Incl. Tax

CLAMP(4GY)

904641019000 904641019000

£2,41

Unit Price Incl. Tax

RELAY ASSY

4XV8195A0000 4XV8195A0000

£120,29

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the ELECTRICAL 2 of your Yamaha XVS1100 of 2000. Let us know if you have any questions.

Select your Yamaha DRAGSTAR model from 2000
