SWITCH / LEVER

ELECTRICAL 1 FOR YAMAHA YZF-R1 1998

ELECTRICAL 2

(1) 4XV-82305-00-00

BLOC D ALLUMAGE

(1) 4XV-82305-10-00

BLOC D ALLUMAGE

(2) 97707-60016-00

SCREW, TRUSS TAP.

(3) 4KM823100200

IGNITION COIL ASSY

(4) 4KM823200200

IGNITION COIL ASSY

(5) 4XV-82309-00-00

FIL, SECONDAIRE

(6) 4XV823700100

PLUG CAP ASSY

(7) 97707-60025-00

SCREW, TRUSS TAP.

(8) 4GY825401000

NEUTRAL SWITCH ASSY

(9) 90430-10148-00

GASKET (1KH,1.0T)

(10) 4XV-82541-00-00

FIL

(11) 4XV857200100

OIL LEVEL GAUGE ASSY

(12) 5Y9-12491-00-00

CLAMP

(13) 913120601400

BOLT (33M)

(14) 90465-08076-00

CLAMP (583)

(15) 3LN-82560-01-00

THERMO SWITCH ASSY

(16) 2YK-83591-00-00

THERMO UNIT

(17) 95027-06010-00

BOLT, FLANGE(4MY)

(18) 4XV-81673-00-00

ROTOR

(19) 93604-29151-00

PIN, DOWEL (3Y1)

(20) 958141004000

BOLT, FLANGE

(21) 90201-107K6-00

WASHER, PLATE(1WG)

(22) 4XV837550400

SENSOR, SPEED

(23) 913120601400

BOLT (33M)

(24) 90465-08028-00

CLAMP (1E6)

(25) 4XV816701100

PICK-UP ASSY

(26) 91317-06012-00

BOLT,SOCKET

(27) 904650805400

CLAMP

(28) 4FM858200100

SERVO MOTOR ASSY

(29) 90462-08225-00

CLAMP(4AJ)

(30) 3GM857520300

SENDER UNIT ASSY, FUEL METER

(31) 42X-85753-00-00

GASKET, SENDER UNIT

(32) 90149-06011-00

SCREW 256241430000

(33) 902020518700

WASHER, PLATE(3MB)

(34) 4XV-81950-00-00

RELAY ASSY (4XV-00)

	Part number	Description	Qty
# 1	4XV-82305-00-00 4XV823050000 4XV823050000	BLOC D ALLUMAGE	Not available	£0,00
# 1	4XV-82305-10-00 4XV823051000 4XV823051000	BLOC D ALLUMAGE	Not available	£0,00
# 2	97707-60016-00 977076001600 977076001600	SCREW, TRUSS TAP.	£0,48
# 3	4XV-82310-00-00 4KM823100200 4XV823100000	IGNITION COIL ASSY	£126,38
# 4	4XV-82320-00-00 4KM823200200 4XV823200000	IGNITION COIL ASSY	£124,84
# 5	4XV-82309-00-00 4XV823090000 4XV823090000	FIL, SECONDAIRE	Not available	£0,00
# 6	4XV-82370-00-00 4XV823700100 4XV823700000	PLUG CAP ASSY	£110,04
# 7	97707-60025-00 977076002500 977076002500	SCREW, TRUSS TAP.	£0,66
# 8	4KM-82540-00-00 4GY825401000 4KM825400000	NEUTRAL SWITCH ASSY	£23,71
# 9	90430-10148-00 904301014800 904301014800	GASKET (1KH, 1.0T)	£2,02
# 10	4XV-82541-00-00 4XV825410000 4XV825410000	FIL	Not available	£0,00
# 11	4XV-85720-00-00 4XV857200000	OIL LEVEL GAUGE ASSY	Not available	£0,00
# 12	5Y9-12491-00-00 5Y9124910000 5Y9124910000	CLAMP	£1,32
# 13	91317-06014-00 913120601400 913170601400	BOLT (33M)	£0,66
# 14	90465-08076-00 904650807600 904650807600	CLAMP (583)	Not available	£0,00
# 15	3LN-82560-01-00 3LN825600100 3LN825600100	THERMO SWITCH ASSY	£57,64
# 16	2YK-83591-00-00 2YK835910000 2YK835910000	THERMO UNIT	£64,42
# 17	95027-06010-00 950270601000 950270601000	BOLT, FLANGE(4MY)	£1,06
# 18	4XV-81673-00-00 4XV816730000 4XV816730000	ROTOR	Not available	£0,00
# 19	93604-29151-00 936042915100 936042915100	PIN, DOWEL (3Y1)	£1,32
# 20	90105-10290-00 958141004000 901051029000	BOLT, FLANGE	£3,55
# 21	90201-107K6-00 90201107K600 90201107K600	WASHER, PLATE(1WG)	£8,59
# 22	4XV-83755-00-00 4XV837550400 4XV837550000	SENSOR, SPEED	£152,48
# 23	91317-06014-00 913120601400 913170601400	BOLT (33M)	£0,66
# 24	90465-08028-00 904650802800 904650802800	CLAMP (1E6)	£3,96
# 25	4XV-81670-00-00 4XV816700000	PICK-UP ASSY	Not available	£0,00
# 26	91317-06012-00 913170601200 913170601200	BOLT, SOCKET	£1,18
# 27	90465-08191-00 904650805400 904650819100	CLAMP	£3,52
# 28	4FM-85820-00-00 4FM858200000	SERVO MOTOR ASSY	Not available	£0,00
# 29	90462-08225-00 904620822500 904620822500	CLAMP(4AJ)	£6,11
# 30	3GM-85752-01-00 3GM857520300 3GM857520100	SENDER UNIT ASSY, FUEL METER	£125,17
# 31	42X-85753-00-00 42X857530000 42X857530000	GASKET, SENDER UNIT	£4,69
# 32	90149-06011-00 901490601100 901490601100	SCREW 256241430000	£2,35
# 33	90202-05193-00 902020518700 902020519300	WASHER, PLATE(3MB)	£0,48
# 34	4XV-81950-00-00 4XV819500000 4XV819500000	RELAY ASSY (4XV-00)	Not available	£0,00

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the ELECTRICAL 1 of your Yamaha YZF-R1 of 1998. Let us know if you have any questions.
